E CUT S

Properties and Applications

Electrode especially used for all cutting, gouging, bevelling and piercing purposes. Particularly suitable for cutting industrial metals like steels, cast irons, non-ferrous metals and also metals which are difficult or impossible to cut with oxyacetylene process. Resulted surface finish is very clean and smooth. E CUT-S should be definetely not left to dry, but should contain certain amount of dampness. Possible to use in DCEN or DCEP. DCEN provides higher metal removal speed.
E Cut S Sert Dolgu

Application Information

Welding Positions :
E Cut S Kaynak Pozisyonu E Cut S Kaynak Pozisyonu E Cut S Kaynak Pozisyonu E Cut S Kaynak Pozisyonu E Cut S Kaynak Pozisyonu E Cut S Kaynak Pozisyonu E Cut S Kaynak Pozisyonu

Polarity:

E Cut S Kutuplama

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)
2.50x350100-150
3.25x350150-220
3.25x450150-210
4.00x450180-250
5.00x450200-310

Packaging Information

Product CodeDiameter x Length (mm)Quantity per BoxBox Gross Weight (kg)Boxes per Outer BoxOuter Box Gross Weight (kg)Packaging Type
18502HREM22.50x350196 pcs4.57313.90Cardboard Box
18502NREM23.25x350116 pcs4.57313.90Cardboard Box
18502PSEM23.25x450124 pcs5.58316.90Cardboard Box
18502SSEM24.00x45082 pcs5.58316.90Cardboard Box
18502VREM25.00x45045 pcs5.08315.40Cardboard Box

Storage & Re-Drying Information

>Don't redry.
