EAL 1100

Standards

AWS/ASME SFA - 5.3 E1100
EN ISO 18273 E Al 1080 A(Al 99.8)
TS EN ISO 18273 E Al 1080 A(Al 99.8)
TS 9604 EL-Al99.5
DIN M. No. 3.0286

Materials

DIN Material
Al 99.0 - Al 99.5 3.0205 - 3.0255
Al 99.9 Mg 0.5 3.3308

Properties and Applications

Special coated electrode for welding pure aluminium. Weld metal has good color matching with base metal and high electrical conductivity. Hold the electrode perpendicularly to workpiece, with a short arc length, during welding. If the thickness is greater than 10 mm or in large workpieces, preheating shall be applied between 150°C to 250°C. Since slag residues are corrosive, they must be completely removed from the weld bead. Electrode serves well as consumable in oxyacetylene welding. The covering being hygroscopic, electrodes must be stored in an absolutely dry location, or redried if required.
Eal 1100 Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisAl
Weld Deposit99.80

Typical Mechanical Values of Weld Metal(%)

Test ConditionYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)
As welded558525

Application Information

Welding Positions :
Eal 1100 Kaynak Pozisyonu Eal 1100 Kaynak Pozisyonu Eal 1100 Kaynak Pozisyonu Eal 1100 Kaynak Pozisyonu

Polarity:

Eal 1100 Kutuplama

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)
2.50x35050-80
3.25x35070-120
4.00x350110-150

Packaging Information

Product CodeDiameter x Length (mm)Quantity per BoxBox Gross Weight (kg)Boxes per Outer BoxOuter Box Gross Weight (kg)Packaging Type
14000HYEM22.50x350224 pcs2.1236.50Tin Box
14000NYEM23.25x350146 pcs2.1236.50Tin Box
14000QYEM24.00x350102 pcs2.1236.50Tin Box

Storage & Re-Drying Information

>It has to be dried at 120°C for 2 hour.
