EC 900

Properties and Applications

Electrode used for gouging and piercing works. Suitable for cleaning faulty welding places, defective surfaces and back-gouging on steels, cast iron, non-ferrous metals. The depth of the groove cut at one gouging should not exceed the diameter of the electrode. For cutting deep gouges the operation should be repeated several times. Electrode should be definitely not left to dry, but should contain certain amount of dampness. Prefered to use in DCEN due to it's higher metal speed.
Ec 900 Sert Dolgu

Application Information

Welding Positions :
Ec 900 Kaynak Pozisyonu Ec 900 Kaynak Pozisyonu Ec 900 Kaynak Pozisyonu Ec 900 Kaynak Pozisyonu Ec 900 Kaynak Pozisyonu Ec 900 Kaynak Pozisyonu Ec 900 Kaynak Pozisyonu

Polarity:

Ec 900 Kutuplama

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)
2.50x350100-150
3.25x350150-230
4.00x350180-250
5.00x350200-350

Packaging Information

Product CodeDiameter x Length (mm)Quantity per BoxBox Gross Weight (kg)Boxes per Outer BoxOuter Box Gross Weight (kg)Packaging Type
18500HREM22.50x350143 pcs3.37310.30Cardboard Box
18500NREM23.25x35090 pcs3.37310.30Cardboard Box
18500QREM24.00x35078 pcs4.07312.40Cardboard Box
18500TREM25.00x35048 pcs4.07312.40Cardboard Box

Storage & Re-Drying Information

>Don't redry.
