ECU Sn7

Standards

AWS/ASME SFA - 5.6 ~ECuSn-C
DIN 1733 EL-CuSn7

Materials

DIN Material ASTM
Cu Sn 2 2.1010 C50700
Cu Sn 4 2.1016 C51100
Cu Sn 6 2.1020 C51900
Cu Sn 8 2.1030 C52100
G-Cu Sn 10 2.1050 C52400
Cu Sn 6 Zn 2.1080
G-Cu Sn 7 Zn Pb 2.1090
G-Cu Sn 6 Zn Ni 2.1093
G-Cu Sn 5 Zn Pb 2.1096

Properties and Applications

Electrode for joining and surfacing of pure copper and copper alloys and also surfacing of steels, cast steels, grey cast iron such as piston arms, sprockets, guides, turbine and centrifugal blades, ship screw propellers, motor collectors etc. For surfacing application, the initial runs should be welded at the lowest possible amperage. To obtain the typical mechanical properties, preheat the workpiece to 350°C and maintain this heat throughout the welding operation.
Ecu Sn7 Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisMnCrNiCuSn
Weld Deposit0.300.300.4091.008.00

Typical Mechanical Values of Weld Metal(%)

Test ConditionYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Hardness (HB)
As welded130290-110

Application Information

Welding Positions :
Ecu Sn7 Kaynak Pozisyonu Ecu Sn7 Kaynak Pozisyonu Ecu Sn7 Kaynak Pozisyonu Ecu Sn7 Kaynak Pozisyonu Ecu Sn7 Kaynak Pozisyonu Ecu Sn7 Kaynak Pozisyonu

Polarity:

Ecu Sn7 Kutuplama

Welding Parameters & Efficiency :

Packaging Information

PRODUCT CODEDiameter x Length (mm)Quantity per box (approx.)Box Net Weight (kg)NUMBER OF BOXES IN PACKAGEPackage Net Weight (kg)Packaging Type
15001GJEM22.50x300102 pcs1.81016.4VAC Box
15001NJEM23.25x35059 pcs2.01021.0VAC Box
15001QJEM24.00x35039 pcs2.0918.6VAC Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.
>It has to be dried at 350°C for 2 hours.
