EH 340

Standards

EN 14700 E Fe1
TS EN 14700 E Fe1
DIN 8555 E 1-UM-400-P

Properties and Applications

Thick basic-covered electrode for producing highly wear resisting hardfacing deposits. It is particularly resistant to metal-to-metal wear, impact and shock. Weld metal can be machined only by using sintered hard metal tipped tools. Even a large number of layers can be deposited without the need of intermediate buffer layers. A tough buffer layer using ESB 42 or EI 307B electrodes is solely required in case of very crack sensitive base metal. EH 340 can be welded in all positions, except vertical-down. Preferred to use with DC, electrode in positive (+) pole and also possible to use with AC.

Typical Applications: Suitable for reconditioning of rails, rail crossings and switch points, wearing parts such as dredger parts, polygon edges, bearing surfaces, striking tools, die tyres, wheel flanges, slide surfaces subject to heavy wear, reconditioning of lower dies, punches and others.
Eh 340 Sert Dolgu

Wear Resistance Types and Microstructure


Abrasion

Adhesion

Impact

Temperature

Corrosion
Low
Medium
High
Very High

Typical Applications

Eh 340 Model Tipik Uygulamalar Eh 340 Model Tipik Uygulamalar Eh 340 Model Tipik Uygulamalar Eh 340 Model Tipik Uygulamalar

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMnCrFe
Weld Deposit0.150.800.602.8095.65

Typical Mechanical Values of Weld Metal(%)

Test ConditionHardness (HRc)Wear Index
As welded4263.14

Application Information

Welding Positions :
Eh 340 Kaynak Pozisyonu Eh 340 Kaynak Pozisyonu Eh 340 Kaynak Pozisyonu Eh 340 Kaynak Pozisyonu Eh 340 Kaynak Pozisyonu Eh 340 Kaynak Pozisyonu

Polarity:

Eh 340 Kutuplama Eh 340 Kutuplama

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)Weld Deposit(Kg)/1Kg Consumed ElectrodeNumber of Electrodes/1Kg Weld DepositWeld Metal Deposition Rate (Kg/h)Efficiency(%)
3.25x350105-1350,67431,13122
4.00x450120-1800,7211,66123
5.00x450170-2400,71132,45123

Packaging Information

Product CodeDiameter X Length (mm)Pieces per BoxKutu AğırlığıNumber Of Boxes Per PackageWeight Of The PackagePackaging Type
18005NEEM23.25x3501515.0315.8Plastic Box
18005NREM23.25x3501515.0315.4Cardboard Box
18005SFEM24.00x450956.5320.4Plastic Box
18005SSEM24.00x450956.5319.9Cardboard Box
18005VSEM25.00x450606.5319.9Cardboard Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.
>It has to be dried at 350°C for 2 hours.
