EI 307R

Standards

AWS/ASME SFA - 5.4 ~E307-16
EN ISO 3581 - A E 18 8 Mn R 12
TS EN ISO 3581 - A E 18 8 Mn R 12
DIN M. No. 1.4370

Properties And Applications

Rutile coated electrode for joining dissimilar steels, depositing buffer layer before hardfacing and claddings on ferritic steels. The weld metal consists of austenitic Cr-Ni-Mn steel with possible small amounts of delta ferrite. The weld metal is highly crack resistant and therefore suited for joining difficult to weld steels and depositing stress relaxing buffer layers on crack sensitive base metal prior to hardfacing deposits. Weld metal work hardens by impact and pressure. Suitable for armour plates, high-manganese steels, rails, cross-overs, crane wheels, idlers, which are subjected to dynamically loading, pressure, impact and abrasion. It is non-scaling up to 850°C and highest operating temperature for dissimilar steel joints is 300°C. In the case of higher temperatures, use ENI 422 electrodes. Easy to use in positional welding and possible to use equally well both with AC and DC.

Approvals & Certificates

Materials

Width Material ASTM
X3CrNiMo17-13-3 1.4436 316
X5CrNiMo17-12-2 1.4401 316

Typical Applications

Ei 307R Model Tipik Uygulamalar Ei 307R Model Tipik Uygulamalar

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMnCrNi
Weld Deposit0.100.456.0019.509.00

Typical Mechanical Values of Weld Metal(%)

Test ConditionYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As welded5006503720°C → 80

Application Information

Welding Positions :
Ei 307R Kaynak Pozisyonu Ei 307R Kaynak Pozisyonu Ei 307R Kaynak Pozisyonu Ei 307R Kaynak Pozisyonu Ei 307R Kaynak Pozisyonu Ei 307R Kaynak Pozisyonu

Polarity:

Ei 307R Kutuplama Ei 307R Kutuplama

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)
2.50x30050-80
3.25x30080-120
3.25x35080-120
4.00x350100-165
5.00x350140-220

Packaging Information

Product CodeDiameter x Length (mm)Quantity per BoxBox Gross Weight (kg)Boxes per Outer BoxOuter Box Gross Weight (kg)Packaging Type
13000GJEM22.50x30096 pcs1.79916.30VAC Box
13000MDEM23.25x30088 pcs2.6238.00Plastic Box
13000MJEM23.25x30062 pcs1.791016.50VAC Box
13000NJEM23.25x35056 pcs2.041020.70VAC Box
13000QJEM24.00x35036 pcs2.041021.00VAC Box
13000TJEM25.00x35025 pcs2.04918.60VAC Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.
>It has to be dried at 350°C for 2 hours.
