EI 308Mo

Datasheet

Standards

AWS/ASME SFA - 5.4	E308Mo-15
EN ISO 3581 - A	E 20 10 3 B 22
TS EN ISO 3581 - A	E 20 10 3 B 22
DIN M. No.	1.4443

Properties And Applications

Basic electrode, particularly designed for welding armour plates, dissimilar steels and for surfacing purposes. The weld metal consists of austenitic Cr-Ni-Mn-Mo stainless steel. It features high resistance to cracking caused by impact and high temperature and is therefore indicated for difficult to weld steels and depositing stress relaxing buffer layers on crack sensitive base metal or beneath hardfacing deposits. Use with DCEP. No pre-heat or post welding heat treatment is needed when welding armour plates. Interpass temperature should not exceed 120°C. Shall be used with shortest possible stick-out distance, at 90° angle to the work piece.

Typical Chemical Values of Weld Metal

Type of Analysis	C	Si	Mn	Cr	Ni	Mo
Weld Deposit	0.08	0.55	1.80	20.00	11.50	2.50

Type of Analysis

Weld Deposit

0.08

0.55

1.80

20.00

11.50

2.50

Typical Mechanical Values of Weld Metal(%)

Test Condition	Yield Strength (N/mm²)	Tensile Strength (N/mm²)	Elongation A5 (%)	Charpy V-Notch Properties (J)
As welded	440	690	40	20°C → 70

Test Condition

Yield Strength (N/mm²)

Tensile Strength (N/mm²)

Elongation A5 (%)

Charpy V-Notch Properties (J)

As welded

440

690

20°C → 70

Application Information

Welding Positions :

Polarity:

Welding Parameters & Efficiency :

Diameter x Length (mm)	Current (A)
2.50x250	50-80
2.50x300	50-80
3.25x300	80-120
4.00x350	100-165
5.00x350	140-220

Packaging Information

Product Code	Diameter x Length (mm)	Quantity per Box	Kutu Brüt Ağırlığı (kg)	Boxes per Outer Box	Koli Ağırlığı (kg)	Packaging Type
13007GJEM2	2.50x300	104 ad	1.81	10	18.50	VAC Box
13007MJEM2	3.25x300	62 ad	1.79	10	16.30	VAC Box
13007QJEM2	4.00x350	46 ad	2.04	9	18.60	VAC Box
13007TJEM2	5.00x350	25 ad	2.07	9	18.80	VAC Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.

>It has to be dried at 350°C for 2 hours.
