EI 310B

Datasheet

Standards

AWS/ASME SFA - 5.4	E310-15
EN ISO 3581 - A	E 25 20 B 12
TS EN ISO 3581 - A	E 25 20 B 12
DIN M. No.	1.4842

Materials

Width	Material	ASTM
GX40CrSi24	1.4745
GX40CrNiSi27-4	1.4823
GX25CrNiSi20-14	1.4832
12CrNi23-13	1.4833	309S
GX40CrNiSi25-12	1.4837
GX15CrNi25-20	1.4840
X15CrNiSi25-21	1.4841	314
	1.4842	310
X8CrNi25-21	1.4845	310S

Properties and Applications

Basic coated stainless steel electrode for welding heat resisting chromium and chromium-nickel steels as well as cast steels. Weld metal deposit is fully austenitic stainless steel, containing 25% chromium and 20% nickel. Suitable for welding heat treatment and industrial fumaces and equipments which are service temperatures up to 1200°C. Weld metal is non-scaling up to 1250°C. Especially high charpy impact energy at low temperatures. Weld metal is not corrosion resistant to sulphurous combustion gases. Used with DCEP.

Typical Chemical Values of Weld Metal

Type of Analysis	C	Si	Mn	Cr	Ni
Weld Deposit	0.10	0.65	1.40	26.00	21.00

Type of Analysis

Weld Deposit

0.10

0.65

1.40

26.00

21.00

Typical Mechanical Values of Weld Metal(%)

Test Condition	Yield Strength (N/mm²)	Tensile Strength (N/mm²)	Elongation A5 (%)	Charpy V-Notch Properties (J)
As welded	440	600	33	20°C → 60

Test Condition

Yield Strength (N/mm²)

Tensile Strength (N/mm²)

Elongation A5 (%)

Charpy V-Notch Properties (J)

As welded

440

600

20°C → 60

Application Information

Welding Positions :

Polarity:

Welding Parameters & Efficiency :

Diameter x Length (mm)	Current (A)	Weld Deposit(Kg)/1Kg Consumed Electrode	Number of Electrodes/1Kg Weld Deposit	Weld Metal Deposition Rate (Kg/h)
2.50x250	50-80	0,54	126	0,72
2.50x300	65-80	0,54	108	0,72
3.25x300	80-120	0,55	65	1,23
4.00x350	110-160	0,55	43	1,67
5.00x350	160-220	0,57	23	2,62

Packaging Information

Product Code	Diameter x Length (mm)	Quantity per Box	Box Gross Weight (kg)	Boxes per Outer Box	Outer Box Gross Weight (kg)	Packaging Type
13014GJEM2	2.50x300	102 pcs	1.79	10	18.50	VAC Box
13014MJEM2	3.25x300	59 pcs	1.79	10	18.50	VAC Box
13014QJEM2	4.00x350	38 pcs	2.04	10	21.00	VAC Box
13014TJEM2	5.00x350	26 pcs	2.04	9	18.60	VAC Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.

>It has to be dried at 350°C for 2 hours.
