EIS 308

Datasheet

Standards

AWS/ASME SFA - 5.4	E308-26
EN ISO 3581 - A	E 19 9 R 53
TS EN ISO 3581 - A	E 19 9 R 53
DIN M. No.	~1.4301

Approvals & Certificates

DoP

TSE

Properties and Applications

Rutile type stainless steel electrode with high recovery (160%) for welding 18Cr/8Ni austenitic stainless steels to mild steels and low alloyed steels and also for surfacing applications on such steels. Weld metal deposit is austenitic-ferritic stainless steels. Possible to use equally well both with AC and DC. High current carrying capacity, since core wire is not made of stainless steel.

Typical Chemical Values of Weld Metal

Type of Analysis	C	Si	Mn	Cr	Ni
Weld Deposit	0.04	0.80	0.80	19.00	10.50

Type of Analysis

Weld Deposit

0.04

0.80

19.00

10.50

Typical Mechanical Values of Weld Metal(%)

Test Condition	Yield Strength (N/mm²)	Tensile Strength (N/mm²)	Elongation A5 (%)	Charpy V-Notch Properties (J)
As welded	460	600	37	20°C → 65

Test Condition

Yield Strength (N/mm²)

Tensile Strength (N/mm²)

Elongation A5 (%)

Charpy V-Notch Properties (J)

As welded

460

600

20°C → 65

Application Information

Welding Positions :

Polarity:

DC(+)

Welding Parameters & Efficiency :

Diameter x Length (mm)	Current (A)
2.00x300	50-80
2.50x350	80-115
3.25x350	110-160
4.00x350	150-200

Packaging Information

Product Code	Diameter X Length (mm)	Pieces per Box (~)	Weight Of The Box (kg)	Boxes Per Package	Weight Of The Package	Packaging Type
13028HJEM5	2.50x350	68	2.0	10	20.7	VAC Box
13028NJEM5	3.25x350	42	2.0	10	21.0	VAC Box
13028QJEM5	4.00x350	28	2.0	9	18.6	VAC Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.

>It has to be dried at 350°C for 2 hours.
