EIS 430

Standards

TS EN ISO 3581 - A E 17 B 62
DIN M. No. ~1.4104

Properties and Applications

Basic type electrode which provides 17% Cr containing ferritic stainless steel weld metal. Generally used for joining of stainless steels with similar composition and surfacing of seating surfaces of steam, water and gas valves, which are made of stainless steels. Also used for corrosion resistant build-up, buffer or wear resistant surfaces on Cr containing steels and stainless steels. Preheating and interpass temperature shall be 200 - 300 °C and post weld heat treatment at 730 - 800 °C is necessary.
Eis 430 Sert Dolgu

Application Information

Welding Positions :
Eis 430 Kaynak Pozisyonu Eis 430 Kaynak Pozisyonu Eis 430 Kaynak Pozisyonu Eis 430 Kaynak Pozisyonu Eis 430 Kaynak Pozisyonu Eis 430 Kaynak Pozisyonu

Polarity:

Eis 430 Kutuplama

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)Weld Deposit(Kg)/1Kg Consumed ElectrodeNumber of Electrodes/1Kg Weld DepositWeld Metal Deposition Rate (Kg/h)Efficiency(%)
2.50x35060-900,59710,71124
3.25x35090-1300,67401,06136

Packaging Information

Product CodeDiameter X Length (mm)Quantity per box (approx.)Box Net Weight (kg)Number Of Boxes In PackagePackage Net Weight (kg)Packaging Type
13031HJEM22.50x35089 pcs2.01021.0VAC Box
13031NJEM23.25x35053 pcs2.01018.6VAC Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.
>It has to be dried at 350°C for 2 hours.
