EM 150

Datasheet

Standards

AWS/ASME SFA - 5.5	E8018-C3
EN ISO 2560 - A	E 46 6 1Ni B 42
TS EN ISO 2560 - A	E 46 6 1Ni B 42

Properties And Applications

Heavy coated basic type electrode, suitable for welding steel constructions, off-shore platforms, bridge, machinery, production and in their root pass applications where low high strength steels and fine grained structural steels used. Weld metal is high crack resistance under difficult operating conditions such as dynamic loads and especially low enviromental temperatures.

Approvals & Certificates

TSE

Materials

Width	DIN
S255N - S460N	StE 255 - StE 460
S225NL	TTSt 35N
S255NL	TStE 255
P310NB	TTSt 41

Typical Chemical Values of Weld Metal

Type of Analysis	C	Si	Mn	Ni
Weld Deposit	0.04	0.20	1.10	1.00

Type of Analysis

Weld Deposit

0.04

0.20

1.10

1.00

Typical Mechanical Values of Weld Metal(%)

Test Condition	Yield Strength (N/mm²)	Tensile Strength (N/mm²)	Elongation A5 (%)	Charpy V-Notch Properties (J)
As welded	530	600	25	-60°C → 60

Test Condition

Yield Strength (N/mm²)

Tensile Strength (N/mm²)

Elongation A5 (%)

Charpy V-Notch Properties (J)

As welded

530

600

-60°C → 60

Application Information

Welding Positions :

Polarity:

Welding Parameters & Efficiency :

Diameter x Length (mm)	Current (A)
2.50x350	60-90
3.25x350	90-140
4.00x450	130-180
5.00x450	190-240
6.00x450	260-320

Packaging Information

Product Code	Diameter x Length (mm)	Quantity per Box	Kutu Brüt Ağırlığı (kg)	Boxes per Outer Box	Koli Ağırlığı (kg)	Packaging Type
12002HKEM2	2.50x350	120 ad	2.54	6	15.50	VAC Box
12002HREM2	2.50x350	240 ad	5.07	3	15.40	Cardboard Box
12002NKEM2	3.25x350	69 ad	2.54	6	15.50	VAC Box
12002NREM2	3.25x350	138 ad	5.07	3	15.40	Cardboard Box
12002SSEM2	4.00x450	99 ad	6.58	3	19.90	Cardboard Box
12002VSEM2	5.00x450	62 ad	6.58	3	19.90	Cardboard Box
12002XSEM2	6.00x450	43 ad	6.58	3	19.90	Cardboard Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.

>It has to be dried at 350°C for 2 hours.
