EM 172

Datasheet

Standards

AWS/ASME SFA - 5.5	E8018-C2
EN ISO 2560 - A	E 46 6 3Ni B 42
TS EN ISO 2560 - A	E 46 6 3Ni B 42

Properties And Applications

Heavy coated basic type electrode for welding fine grained structural steels and especially cryogenic steels. Electrode produces tough and crack-free welded joints. Weld deposit is of extremely high metallurgical purity and very low hydrogen content. Owing to high crack resistance under difficult conditions such as dynamic loads and low service temperatures up to -60°C. It is suitable for use in welding of storage tanks and piping which are subjected to low temperatures. Electrode features a stable and concentrated arc. Especially 2,50 mm and 3,25 mm diameters are well-suited for positional welding. Welds are of X-ray quality.

Materials

Width	DIN
S225NL	TTSt 35 V
S255NL - S420NL	TStE 255 - TStE 420
12Ni14	10 Ni 14

Typical Chemical Values of Weld Metal

Type of Analysis

C

Si

Mn

Ni

Weld Deposit

0.05

0.30

0.90

3.50

Typical Mechanical Values of Weld Metal(%)

Test Condition

Yield Strength (N/mm²)

Tensile Strength (N/mm²)

Elongation A5 (%)

Charpy V-Notch Properties (J)

As welded

500

570

22

-60°C → 50

Application Information

Welding Positions :

Em 172 Kaynak Pozisyonu

Em 172 Kaynak Pozisyonu

Em 172 Kaynak Pozisyonu

Em 172 Kaynak Pozisyonu

Em 172 Kaynak Pozisyonu

Em 172 Kaynak Pozisyonu

Polarity:

Em 172 Kutuplama

Welding Parameters & Efficiency :

Diameter x Length (mm)	Current (A)
2.50x350	60-90
3.25x350	90-140
4.00x450	130-180

Packaging Information

Product Code	Diameter x Length (mm)	Quantity per Box	Kutu Brüt Ağırlığı (kg)	Boxes per Outer Box	Koli Ağırlığı (kg)	Packaging Type
12008HREM2	2.50x350	234 ad	4.57	3	13.90	Cardboard Box
12008NREM2	3.25x350	133 ad	4.57	3	13.90	Cardboard Box
12008SSEM2	4.00x450	100 ad	6.58	3	19.90	Cardboard Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.

>It has to be dried at 350°C for 2 hours.
