EM 176

Standards

AWS/ASME SFA - 5.5 E9018-G
EN ISO 18275 - A E 62 6 Mn2NiMo B 42
TS EN ISO 18275 - A E 62 6 Mn2NiMo B 42

Properties And Applications

Heavy coated basic type electrode for welding fine grained and low alloy steels which will be subsequently normalized or normalized + tempered after welding. Weld deposit is tough and crack-free and has a low hydrogen content. Especially 2,50 mm and 3,25 mm diameters well suited for easy positional welding. Welds are of X-ray quality.

Approvals & Certificates

Materials

Width DIN
S355N - S500N StE 355 - StE 500

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMnNiMo
Weld Deposit0.050.301.602.000.40

Typical Mechanical Values of Weld Metal(%)

Test ConditionYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As welded69576519-60°C → 60

Application Information

Welding Positions :
Em 176 Kaynak Pozisyonu Em 176 Kaynak Pozisyonu Em 176 Kaynak Pozisyonu Em 176 Kaynak Pozisyonu Em 176 Kaynak Pozisyonu Em 176 Kaynak Pozisyonu

Polarity:

Em 176 Kutuplama

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)
3.25x35090-140
4.00x450130-180
5.00x450180-240

Packaging Information

Product CodeDiameter x Length (mm)Quantity per BoxBox Gross Weight (kg)Boxes per Outer BoxOuter Box Gross Weight (kg)Packaging Type
12010NREM23.25x350132 pcs4.57313.90Cardboard Box
12010SSEM24.00x45096 pcs6.58319.90Cardboard Box
12010VSEM25.00x45064 pcs6.58319.90Cardboard Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.
>It has to be dried at 350°C for 2 hours.
