EM 235

Standards

AWS/ASME SFA - 5.5 E8015-B6 H4R
EN ISO 3580 - A E CrMo5 B 42 H5
TS EN ISO 3580 - A E CrMo5 B 42 H5

Approvals & Certificates

Materials

EN DIN ASTM
13CrMo4-5 13CrMo4-4
10CrMo9-10 12CrMo19-5
14MoV6-3
X12CrMo5
A182-F5
A213-T5
A335-P5
A336-F5
A387-Grade 5

Properties and Applications

Basic type electrode for welding creep resistant steels. Weld metal matches the composition of steel grade 12CrMo19-5 featuring equal resistance to high-pressure hydrogen attack, creep resistance and creep rupture strength. Typical applications are : petrochemical process plants, hydrocrackers in chemical industries. Suitable to use in pressure vessels and boilers subject to operating temperatures up to 600°C. Weld metal has a low diffusible hydrogen content (4ml/100g). Preheating, interpass temperature and post weld heat treatment should be done in accordance with base metal to be welded.
Em 235 Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMnCrMo
Weld Deposit0.070.200.605.300,50

Typical Mechanical Values of Weld Metal(%)

Test ConditionYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
Isıl İşlem Sonrası (740°C 1 Saat)5106102120°C → 120

Application Information

Welding Positions :
Em 235 Kaynak Pozisyonu Em 235 Kaynak Pozisyonu Em 235 Kaynak Pozisyonu Em 235 Kaynak Pozisyonu Em 235 Kaynak Pozisyonu Em 235 Kaynak Pozisyonu

Polarity:

Em 235 Kutuplama DC(+)

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)Weld Deposit(Kg)/1Kg Consumed ElectrodeNumber of Electrodes/1Kg Weld DepositWeld Metal Deposition Rate (Kg/h)Efficiency(%)
2.50x35060-900,7820,7120
3.25x35090-1300,7440,99120
4.00x450130-1800,7321,34120
5.00x450190-2300,7211,79120

Packaging Information

Product CodeDiameter X Length (mm)Pieces per Box (~)Weight Of The Box (kg)Number Of Boxes Per PackageWeight Of The PackagePackaging Type
12022HKEM22.50x3501122.5615.5VAC Box
12022HREM22.50x3502014.5313.9Cardboard Box
12022NKEM23.25x350632.5615.5VAC Box
12022NREM23.25x3501265.0315.4Cardboard Box
12022SSEM24.00x450906.5319.9Cardboard Box
12022VSEM25.00x450666.5319.9Cardboard Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.
>It has to be dried at 350°C for 2 hours.
