EM 243

Datasheet

Standards

AWS/ASME SFA - 5.5

E12018-G

Properties and Applications

Basic type electrode for welding cementation steels and 1% Cr, 2.5% Ni, 0.7% Mo containing steels and cast steels. Suitable to use in machine building and construction of apparatus, as well as for repair welding of components made of similar steels grades. Preheating, interpass temperature and post-weld heat treatment should be done in accordance with base metal to be welded.

Typical Chemical Values of Weld Metal

Type of Analysis	C	Si	Mn	Cr	Ni	Mo
Weld Deposit	0.04	0,50	0.60	1.10	2.40	0.75

Type of Analysis

Weld Deposit

0.04

0,50

0.60

1.10

2.40

0.75

Typical Mechanical Values of Weld Metal(%)

Test Condition	Yield Strength (N/mm²)	Tensile Strength (N/mm²)	Elongation A5 (%)	Hardness (HB)	Charpy V-Notch Properties (J)
As welded	790	870	18	300	20°C → 60

Test Condition

Yield Strength (N/mm²)

Tensile Strength (N/mm²)

Elongation A5 (%)

Hardness (HB)

Charpy V-Notch Properties (J)

As welded

790

870

300

20°C → 60

Application Information

Welding Positions :

Polarity:

Welding Parameters & Efficiency :

Diameter x Length (mm)	Current (A)	Weld Deposit(Kg)/1Kg Consumed Electrode	Number of Electrodes/1Kg Weld Deposit	Weld Metal Deposition Rate (Kg/h)	Efficiency(%)
3.25x350	90-130	0,72	44	1,14	125
5.00x450	190-230	0,7	25	1,98	125
4.00x450	140-180	0,71	36	1,65	125
2.50x350	60-90	0,72	69	0,95	125

Packaging Information

PRODUCT CODE	Diameter x Length (mm)	Quantity per box (approx.)	Box Net Weight (kg)	NUMBER OF BOXES IN PACKAGE	Package Net Weight (kg)	Packaging Type
12024HREM2	2.50x350	225 pcs	4.5	3	13.8	Cardboard Box
12024NREM2	3.25x350	152 pcs	5.0	3	15.4	Cardboard Box
12024SSEM2	4.00x450	100 pcs	6.5	3	19.9	Cardboard Box
12024VSEM2	5.00x450	63 pcs	6.5	3	19.9	Cardboard Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.

>It has to be dried at 350°C for 2 hours.
