EM 253

Standards

AWS/ASME SFA - 5.5 E11018-G

Properties and Applications

Basic type electrode for welding hot work tool steels and cast steels with similar composition, which are subjected to high temperatures up to 550-600°C. Suitable for welding Cr, Mo, V, W containing low alloy steels and hot work tool steels. Also suitable for surfacing and hardfacing on machine parts, forging and drawing dies, shafts which were made of hot work tool steels and similiar compositions. Preheating, interpass temperature and post-weld heat treatment should be done in accordance with base metal to be welded.
Em 253 Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMnCrMoVW
Weld Deposit0.100.901.053.500.700.550.60

Typical Mechanical Values of Weld Metal(%)

Test ConditionYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Hardness (HRc)Charpy V-Notch Properties (J)
As welded800920184420°C → 45

Application Information

Welding Positions :
Em 253 Kaynak Pozisyonu Em 253 Kaynak Pozisyonu Em 253 Kaynak Pozisyonu Em 253 Kaynak Pozisyonu Em 253 Kaynak Pozisyonu Em 253 Kaynak Pozisyonu

Polarity:

Em 253 Kutuplama

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)Weld Deposit(Kg)/1Kg Consumed ElectrodeNumber of Electrodes/1Kg Weld DepositWeld Metal Deposition Rate (Kg/h)Verimlilik(%)
2.00x30040-600,69660,98129
2.50x35060-900,69570,98129
3.25x35090-1200,68411,17129
4.00x450130-1800,68321,79129
5.00x450190-2300,68212,19129

Packaging Information

Product CodeDiameter X Length (mm)Kutudaki Miktar (yakl)Kutu Net Ağırlığı (kg)Number Of Boxes In PackageKoli Net Ağırlığı (kg)Packaging Type
12026DRAM12.00x300280 ad3.2619.4Cardboard Box
12026HREM22.50x350237 ad5.0315.4Cardboard Box
12026NREM23.25x350136 ad5.0315.4Cardboard Box
12026SSEM24.00x45094 ad6.5319.9Cardboard Box
12026VSEM25.00x45062 ad6.5319.9Cardboard Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.
>It has to be dried at 350°C for 2 hours.
