EM 295

Datasheet

Standards

AWS/ASME SFA - 5.5	E9015-B91 H4R
EN ISO 3580 - A	E (CrMo91) B 42 H5

Properties And Applications

Basic type, covered electrode for welding high temperature creep resistant steels of type 9Cr-1Mo-V-Nb-N with operating temperatures of up to 650°C. Suitable for welding piping and components produced from P91, F91 and T91 steels. Can be used both in thin walled and thick walled pipes and casting successfully, especially in power plants, chemical and petrochemical industry. Welds are X-ray quality.

Materials

Width	ASTM
X10CrMoVNb9-1
	A182-F91
	A213-T91
	A335-P91
	A336-P91
	A387-Grade 91

Typical Chemical Values of Weld Metal

Type of Analysis	C	Si	Mn	Cr	Ni	Mo	V	Nb	P	S	N
Weld Deposit	0.10	0.20	0.75	9.25	0.55	1.00	0.20	0.04	0.01	0.01	0.04

Type of Analysis

Weld Deposit

0.10

0.20

0.75

9.25

0.55

1.00

0.20

0.04

0.01

0.04

Typical Mechanical Values of Weld Metal(%)

Test Condition	Yield Strength (N/mm²)	Tensile Strength (N/mm²)	Elongation A5 (%)	Charpy V-Notch Properties (J)
Isıl İşlem Sonrası (760°C 2 Saat)	620	730	20	20°C → 70

Test Condition

Yield Strength (N/mm²)

Tensile Strength (N/mm²)

Elongation A5 (%)

Charpy V-Notch Properties (J)

Isıl İşlem Sonrası (760°C 2 Saat)

620

730

20°C → 70

Application Information

Welding Positions :

Polarity:

Welding Parameters & Efficiency :

Diameter x Length (mm)	Current (A)
2.50x350	60-90
3.25x350	90-130
4.00x450	130-180
5.00x450	170-240

Packaging Information

Product Code	Diameter x Length (mm)	Quantity per Box	Kutu Brüt Ağırlığı (kg)	Boxes per Outer Box	Koli Ağırlığı (kg)	Packaging Type
12030HKEM2	2.50x350	121 ad	2.54	6	15.50	VAC Box
12030NKEM2	3.25x350	73 ad	2.54	6	15.50	VAC Box
12030SKEM2	4.00x450	38 ad	2.56	6	15.60	VAC Box
12030SSEM2	4.00x450	99 ad	6.58	3	19.90	Cardboard Box
12030VKEM2	5.00x450	23 ad	2.56	6	15.60	VAC Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.

>It has to be dried at 350°C for 2 hours.
