ENI 406 (Mo)

Standards

AWS/ASME SFA - 5.15 ENiCu-B
EN ISO 1071 E C NiCu-B 3
TS EN ISO 1071 E C NiCu-B 3

Materials

DIN
GG 10 - GG 35
GTS 35-10 - GTS 70-02
GGG 40 - GGG 70
GTW 35-04 - GTW S 38-12

Properties and Applications

Electrode having a nickel-copper core wire for welding cast iron without or with low preheating (up to 300°C). Well-suited to welding cast iron with lamellar graphite, white and black heart malleable cast iron, nodular cast iron. Weld metal closely matches colour of base metal. Electrode is preferably used for making filler and cover passes of for filling-up shrinkage cavities. Weld metal is machinable. Provides easy arc striking and restriking, stable arc, smooth bead surface. Weld short beads, about 30 to 50 mm long. In order to reduce weld residual stresses, hammer-peen welds slightly before cooling.
Eni 406 (Mo) Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMnNiTiCuFe
Weld Deposit0,500,501.0064.000,5030.003.50

Typical Mechanical Values of Weld Metal(%)

Test ConditionHardness (HB)
As welded160

Application Information

Welding Positions :
Eni 406 (Mo) Kaynak Pozisyonu Eni 406 (Mo) Kaynak Pozisyonu Eni 406 (Mo) Kaynak Pozisyonu Eni 406 (Mo) Kaynak Pozisyonu Eni 406 (Mo) Kaynak Pozisyonu Eni 406 (Mo) Kaynak Pozisyonu

Polarity:

Eni 406 (Mo) Kutuplama Eni 406 (Mo) Kutuplama

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)
2.50x30050-70
3.25x30090-110
4.00x400110-140
5.00x400140-200

Packaging Information

Product CodeDiameter x Length (mm)Quantity per BoxBox Gross Weight (kg)Boxes per Outer BoxOuter Box Gross Weight (kg)Packaging Type
16000GBEM22.50x30059 pcs1.11100.00
16001GJEM22.50x300105 pcs1.80916.40VAC Box
16001MBEM23.25x30036 pcs1.11100.00
16001MJEM23.25x30062 pcs1.80916.40VAC Box
16001RBEM24.00x40032 pcs0.00100.00
16001RJEM24.00x40041 pcs2.31921.00VAC Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.
> It has to be dried at 150°C for 1 hour.
