ENI 416 (NiFe)

Standards

AWS/ASME SFA - 5.15 ENiFe-CI
EN ISO 1071 E C NiFe-CI 3
TS EN ISO 1071 E C NiFe-CI 3

Materials

DIN
GGG 40.3 - GGG 70
GTS 35-10 - GTS 70-02
GTW 35-04 - GTW S 38-12

Properties and Applications

Electrode having a nickel-iron core wire, for welding cast iron with or without preheating. The weld metal features a low coefficient of thermal expansion and as a result, little shrinkage. It has higher strength properties than pure nickel weld metal and is therefore preferably used for welding nodular cast iron, white and black heart malleable cast iron, as well as austenitic nodular cast iron or joining these metals to components made of steel, copper or nickel materials. Easy arc striking and restriking, stable arc, smooth bead. Weld metal is machinable. Weld short beads.
Eni 416 (NiFe) Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMnNiAlFe
Weld Deposit0.451.600.6552.000.8044.50

Typical Mechanical Values of Weld Metal(%)

Test ConditionHardness (HB)
As welded210

Application Information

Welding Positions :
Eni 416 (NiFe) Kaynak Pozisyonu Eni 416 (NiFe) Kaynak Pozisyonu Eni 416 (NiFe) Kaynak Pozisyonu Eni 416 (NiFe) Kaynak Pozisyonu Eni 416 (NiFe) Kaynak Pozisyonu Eni 416 (NiFe) Kaynak Pozisyonu

Polarity:

Eni 416 (NiFe) Kutuplama Eni 416 (NiFe) Kutuplama

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)Weld Deposit(Kg)/1Kg Consumed ElectrodeNumber of Electrodes/1Kg Weld DepositWeld Metal Deposition Rate (Kg/h)Verimlilik(%)
2.50x30050-800,7890,47121
3.25x30080-1100,71530,7997
4.00x400110-1400,73260,82108

Packaging Information

Product CodeDiameter X Length (mm)Kutudaki Miktar (yakl)Kutu Net Ağırlığı (kg)Number Of Boxes In PackageKoli Net Ağırlığı (kg)Packaging Type
16003GBEM22.50x30060 ad1.0120.0Plastic Box
16003GDEM22.50x300160 ad2.538.0Plastic Box
16003GJEM22.50x300112 ad1.81018.2VAC Box
16003M9EM13.25x30015 ad0.33511.6Blister
16003MBEM23.25x30037 ad1.01011.3Plastic Box
16003MDEM23.25x30093 ad2.538.0Plastic Box
16003MJEM23.25x30065 ad1.81018.2VAC Box
16003QJEM24.00x35044 ad2.0100.0VAC Box
16003RBEM24.00x40032 ad1.81019.0Plastic Box
16003RJEM24.00x40048 ad2.5923.1VAC Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.
> It has to be dried at 150°C for 1 hour.
