ENI 422

Standards

AWS/ASME SFA - 5.11 ENiCrFe-3
EN ISO 14172 E Ni 6182
TS EN ISO 14172 E Ni 6182
DIN M. No. 2.4620

Materials

DIN Material
X 10 Ni Cr Al Ti 32 20 1.4876
X 5 Ni Cr Al Ti 31 20 1.4958
Ni Cr 15 Fe 2.4816

Properties and Applications

Basic coated electrode with Ni-Cr-Fe type nickel base deposit. Used for repairing and joining of nickel alloys, 5 - 9% Nickel steels, cryogenic stainless steels down to -196°C, Incoloy 800 and other high temperature steels. Provides a weld metal which has a operating temperatures from -196°C to 800°C. Used for joining dissimilar materials as stainless steels/low alloyed steels, stainless steels/Nickel alloys, buffering of difficult to weld steels. Weld metal deposit is insensitive to cracks, has very good resistance to acids, salts and alkaline solutions, molten salt (e.g. cyanide) in oxidizing and carburization atmospheres (avoid a sulphurous atmosphere). Generally used for welding on oven parts, burners, heat treatment equipment, cement works, moulds, transport and storage tanks of liquid gas. Has a wide range of application in chemical industry, petrochemical industry, glassworks, civil engineering, repairing and maintenance workshops.
Eni 422 Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMnCrNiMoNbFe
Weld Deposit0.030,506.0016.0069.200.022.006.25

Typical Mechanical Values of Weld Metal(%)

Test ConditionYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As welded4006403220°C → 120-196°C → 100

Application Information

Welding Positions :
Eni 422 Kaynak Pozisyonu Eni 422 Kaynak Pozisyonu Eni 422 Kaynak Pozisyonu Eni 422 Kaynak Pozisyonu Eni 422 Kaynak Pozisyonu Eni 422 Kaynak Pozisyonu

Polarity:

Eni 422 Kutuplama

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)Weld Deposit(Kg)/1Kg Consumed ElectrodeNumber of Electrodes/1Kg Weld DepositWeld Metal Deposition Rate (Kg/h)Verimlilik(%)
2.50x30050-700,58900.72116
3.25x35070-950,63441,16117
4.00x35090-1200,65281,56118
5.00x450120-1600,67142,87118

Packaging Information

Product CodeDiameter X Length (mm)Kutudaki Miktar (yakl)Kutu Net Ağırlığı (kg)Number Of Boxes In PackageKoli Net Ağırlığı (kg)Packaging Type
16005GJEM22.50x30092 ad1.8916.3VAC Box
16005GREM22.50x300211 ad4.0312.3Cardboard Box
16005NJEM23.25x35069 ad2.5615.5VAC Box
16005NREM23.25x350139 ad5.0315.4Cardboard Box
16005QREM24.00x35093 ad5.0315.4Cardboard Box
16005VSEM25.00x45058 ad6.5319.9Cardboard Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.
>
