ENI 440


AWS/ASME SFA - 5.11 ENiCu-7
EN ISO 14172 E Ni 4060
TS EN ISO 14172 E Ni 4060
DIN M. No. 2.4366


DIN Material
Ni Cu 30 Fe 2.4360
LC-Ni Cu 30 Fe 2.4361
Ni Cu 30 Al 2.4375

Properties and Applications

Electrode having monel core wire, designed for joining and surfacing welds of Monel-clad steels. Suitable for joining Monel alloys to steel weld surfacing of steel with corrosion-resistant Monel coating. The weld metal is free of porosity and resistant to many chemicals. Suitable for applications with working temperatures from -196°C to 450°C. Weld groove preparation and cleaning should be done carefully. Generally welding should be done in horizontal position with short stick-out distance without weaving. Due to porosity risk of the weld metal, welding and striking shall be started on end plate. Possible to use with DCEP.
Eni 440 Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisCMnNiCuFe
Weld Deposit0.011.0065.0030.002.50

Typical Mechanical Values of Weld Metal(%)

Test ConditionYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As welded3205504020°C → 120

Application Information

Welding Positions :
Eni 440 Kaynak Pozisyonu Eni 440 Kaynak Pozisyonu Eni 440 Kaynak Pozisyonu Eni 440 Kaynak Pozisyonu Eni 440 Kaynak Pozisyonu Eni 440 Kaynak Pozisyonu


Eni 440 Kutuplama DC(+)

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)Weld Deposit(Kg)/1Kg Consumed ElectrodeNumber of Electrodes/1Kg Weld DepositWeld Metal Deposition Rate (Kg/h)Efficiency(%)

Packaging Information

Product CodeDiameter X Length (mm)Pieces per Box (~)Weight Of The Box (kg)Boxes Per PackageWeight Of The PackagePackaging Type
16004GJEM22.50x3001091.8916.3VAC Box
16004MJEM23.25x300631.8916.4VAC Box
16004NJEM23.25x350612.0100.0VAC Box
16004RJEM24.00x400392.3921.0VAC Box
16004UJEM25.00x400262.3921.0VAC Box

Storage & Re-Drying Information

>It has to be dried at 200°C for 2 hour.
>It can be dried maximum 5 times.
