ESB 44

Datasheet

Standards

AWS/ASME SFA - 5.1	E7016 H8
EN ISO 2560 - A	E 38 2 B 12 H10
TS EN ISO 2560 - A	E 38 2 B 12 H10

Properties And Applications

Suitable for fabrication and repair welding of dynamically loaded steel constructions, machines and agricultural equipments, workshop and maintenence welding. Smooth and clean welds, blending into base metal without undercuts. Excellent gap bridging properties. The double covering of this electrode produces a stable, concentrated and directed arc, thus being ideally suited for root pass and positional welding and is suited for AC welding. Welds are of X-ray quality.

Approvals & Certificates

TSE

DNV

TUV

Materials

EN	DIN
S185 - S355J0	St 33- St 52.3
P235GH, P265GH	H I, H II
P295GH	17Mn4
P235TR2 - P355T2	St37.4 - St 52.4
P235G1TH, P255G1TH	StE 35.8 - StE 45.8
L210 - L360NB	StE 210.7 - StE 360.7
S255N - S355N	StE 255- StE 355
GE 200, GE 240, GE 260	GS 38, GS 45, GS 52
	AH 32, EH 36
	A, B, D, E

Typical Chemical Values of Weld Metal

Type of Analysis	C	Si	Mn
Weld Deposit	0.06	0.65	1.00

Type of Analysis

Weld Deposit

0.06

0.65

1.00

Typical Mechanical Values of Weld Metal(%)

Test Condition	Yield Strength (N/mm²)	Tensile Strength (N/mm²)	Elongation A5 (%)	Charpy V-Notch Properties (J)
As welded	450	550	25	-20°C → 70	-30°C → 55

Test Condition

Yield Strength (N/mm²)

Tensile Strength (N/mm²)

Elongation A5 (%)

Charpy V-Notch Properties (J)

As welded

450

550

-20°C → 70

-30°C → 55

Application Information

Welding Positions :

Polarity:

Welding Parameters & Efficiency :

Packaging Information

Product Code	Diameter X Length (mm)	Kutudaki Miktar (yakl)	Kutu Net Ağırlığı (kg)	Number Of Boxes In Package	Koli Net Ağırlığı (kg)	Packaging Type
11202EREM2	2.00x350	394 ad	5.0	3	15.4	Cardboard Box
11202HBEM2	2.50x350	50 ad	1.0	10	11.3	Plastic Box
11202HKEM2	2.50x350	126 ad	2.5	6	15.6	VAC Box
11202HQEM2	2.50x350	126 ad	2.5	6	15.4	Cardboard Box
11202HREM2	2.50x350	251 ad	5.0	3	15.4	Cardboard Box
11202N9EM1	3.25x350	15 ad	0.3	30	11.1	Blister
11202NBEM2	3.25x350	30 ad	1.0	10	11.3	Plastic Box
11202NKEM2	3.25x350	76 ad	2.5	6	15.5	VAC Box
11202NQEM2	3.25x350	76 ad	2.5	6	15.4	Cardboard Box
11202NREM2	3.25x350	151 ad	5.0	3	15.4	Cardboard Box
11202PKEM2	3.25x450	59 ad	2.5	6	15.6	VAC Box
11202PSEM2	3.25x450	153 ad	6.5	3	19.9	Cardboard Box
11202QBEM2	4.00x350	20 ad	1.0	10	11.3	Plastic Box
11202QKEM2	4.00x350	49 ad	2.5	6	15.5	VAC Box
11202SBEM2	4.00x450	15 ad	1.0	10	11.3	Plastic Box
11202SKEM2	4.00x450	37 ad	2.5	6	15.6	VAC Box
11202SSEM2	4.00x450	97 ad	6.5	3	19.9	Cardboard Box
11202VKEM2	5.00x450	25 ad	2.5	6	15.6	VAC Box
11202VSEM2	5.00x450	64 ad	6.5	3	19.9	Cardboard Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.

>It has to be dried at 350°C for 2 hours.
