ESB 50

Standards

AWS/ASME SFA - 5.1 E7018 H8
EN ISO 2560 - A E 42 3 B 42 H5
TS EN ISO 2560 - A E 42 3 B 42 H5

Properties And Applications

Suitable for welding fabrication of dynamically loaded heavy steel constructions, bridge, shipbuilding, pipe line, pressure vessels, tanks, boiler and machines where mechanical properties are required. Weld metal exhibits good toughness properties down to -50°C and produce tough and crack-free welded joints even on steels having a carbon content of up to 0.4%. Weld metal recovery amounts to approx. 120%. Welds are of X-ray quality. Electrode is suitable for depositing buffer layers on higher carbon steels.

Approvals & Certificates

Materials

Width DIN
S185 - S355J0 St 33- St 52.3
E295 St 50.2
P235GH, P265GH H I, H II
P295GH, P355GH 17Mn4, 19Mn5
P235TR2 - P355T2 St37.4 - St 52.4
P235G1TH, P255G1TH StE 35.8 - StE 45.8
L210 - L360NB StE 210.7 - StE 360.7
L290MB - L360MB StE 290.7 TM - StE 360.7 TM
S255N - S420N StE 255- StE 420
GE 200, GE 240, GE 260 GS 38, GS 45, GS 52
AH 32, EH 36
A, B, D, E

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMn
Weld Deposit0.070.351.45

Typical Mechanical Values of Weld Metal(%)

Test ConditionYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As welded47056029-30°C → 100-50°C → 60

Application Information

Welding Positions :
Esb 50 Kaynak Pozisyonu Esb 50 Kaynak Pozisyonu Esb 50 Kaynak Pozisyonu Esb 50 Kaynak Pozisyonu Esb 50 Kaynak Pozisyonu Esb 50 Kaynak Pozisyonu

Polarity:

Esb 50 Kutuplama

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)
2.00x30040-60
2.00x35040-60
2.50x35060-90
3.25x35090-150
3.25x45090-140
4.00x350140-190
4.00x450140-190
5.00x450190-250
6.00x450260-340

Packaging Information

Product CodeDiameter x Length (mm)Quantity per BoxBox Gross Weight (kg)Boxes per Outer BoxOuter Box Gross Weight (kg)Packaging Type
11205EBEM22.00x35067 pcs1.111011.30
11205EREM22.00x350267 pcs4.07312.40Cardboard Box
11205HBEM22.50x35045 pcs1.111011.30
11205HJEM22.50x350111 pcs2.54615.50VAC Box
11205HQEM22.50x350111 pcs2.54615.40Cardboard Box
11205HREM22.50x350223 pcs5.06315.40Cardboard Box
11205NBEM23.25x35028 pcs1.111011.30
11205NJEM23.25x35070 pcs2.54615.50VAC Box
11205NQEM23.25x35070 pcs2.54615.40Cardboard Box
11205NREM23.25x350141 pcs5.06315.40Cardboard Box
11205PSEM23.25x450144 pcs6.58319.90Cardboard Box
11205QJEM24.00x35047 pcs2.54615.50VAC Box
11205QQEM24.00x35047 pcs2.54615.40Cardboard Box
11205QREM24.00x35094 pcs5.07315.40Cardboard Box
11205SSEM24.00x45095 pcs6.58319.90Cardboard Box
11205VSEM25.00x45062 pcs6.58319.90Cardboard Box
11205XSEM26.00x45044 pcs6.58319.90Cardboard Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.
>It has to be dried at 350°C for 2 hours.
