ESB 51

Standards

AWS/ASME SFA - 5.1 E7018-1 H4
EN ISO 2560 - A E 42 4 B 42 H5
TS EN ISO 2560 - A E 42 4 B 42 H5

Approvals & Certificates

Materials

EN DIN
S185 - S355J2 St 33- St 52.3
P235GH, P265GH H I, H II
P295GH, P355GH 17Mn4, 19Mn5
P235TR2 - P355T2 St37.4 - St 52.4
P235G1TH, P255G1TH StE 35.8 - StE 45.8
L210 - L360NB StE 210.7 - StE 360.7
L290MB - L360MB StE 290.7 TM - StE 360.7 TM
S255N - S420N StE 255- StE 420
GE 200, GE 240, GE 260 GS 38, GS 45, GS 52
AH 32, EH 36
A, B, D, E

Properties and Applications

Suitable for welding dynamically loaded structures, like bridge, heavy steel construction, pipeline joints, tanks, pressure vessels, boilers and machinery, where high strength and toughness are required. The weld metal has low diffusible hydrogen and high notch impact toughness down to -40°C. It has 115% weld metal efficiency. Provides smooth and clean weld beads, mixing with the base metal without undercut. Good gap bridging and position welding capability. The welds are of X-ray quality. It is also suitable for making buffer passes in high-carbon steels.
Esb 51 Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMn
Weld Deposit0.070.401.20

Typical Mechanical Values of Weld Metal(%)

Test ConditionYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As welded47056028-40°C → 100-51°C → 80

Application Information

Welding Positions :
Esb 51 Kaynak Pozisyonu Esb 51 Kaynak Pozisyonu Esb 51 Kaynak Pozisyonu Esb 51 Kaynak Pozisyonu Esb 51 Kaynak Pozisyonu Esb 51 Kaynak Pozisyonu

Polarity:

Esb 51 Kutuplama DC(+)

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)
2.50x35060-90
3.25x35090-150
4.00x450140-190
5.00x450200-250
6.00x450260-340

Packaging Information

Product CodeDiameter X Length (mm)Pieces per Box (~)Weight Of The Box (kg)Boxes Per PackageWeight Of The PackagePackaging Type
11207HRFM22.50x3502175.0315.4Cardboard Box
11207NRFM23.25x3501375.0315.4Cardboard Box
11207SRFM24.00x450695.0315.4Cardboard Box
11207VSFM25.00x450616.5319.9Cardboard Box
11207XSFM26.00x450406.5319.9Cardboard Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.
>It has to be dried at 350°C for 2 hours.
