ESB 52

Standards

AWS/ASME SFA - 5.1 E7018-1 H4R
EN ISO 2560 - A E 42 5 B 42 H5
TS EN ISO 2560 - A E 42 5 B 42 H5
CSA W48-18 E4918-1-H4

Approvals & Certificates

Materials

EN DIN
S185 - S355J0 St 33- St 52.3
E295 St 50.2
P235GH, P265GH H I, H II
P295GH, P355GH 17Mn4, 19Mn5
P235TR2 - P355T2 St37.4 - St 52.4
P235G1TH, P255G1TH StE 35.8 - StE 45.8
L210 - L360NB StE 210.7 - StE 360.7
L290MB - L360MB StE 290.7 TM - StE 360.7 TM
S255N - S420N StE 255- StE 420
GE 200, GE 240, GE 260 GS 38, GS 45, GS 52
AH 32, EH 36
A, B, D, E

Properties and Applications

Suitable for welding of steel constructions, bridge, dam, thermal power plants, petrochemical insdustry, shipbuilding, high strength pipe-lines, pressure vessels, tanks, which are dynamically loaded and require high mechanical properties. The weld metal has a very low hydrogen content and is resistant to ageing. Produces tough and crack-free welded joints, also suite for welding steels having a carbon content of up to 0.6 % and joining of rails. Good operating characteristic, also in root pass and positional welding. Very good gap bridging properties. Welds are of X-ray quality.
Esb 52 Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMn
Weld Deposit0.070.401.20

Typical Mechanical Values of Weld Metal(%)

Test ConditionYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As welded46055028-46°C → 110-50°C → 100

Application Information

Welding Positions :
Esb 52 Kaynak Pozisyonu Esb 52 Kaynak Pozisyonu Esb 52 Kaynak Pozisyonu Esb 52 Kaynak Pozisyonu Esb 52 Kaynak Pozisyonu Esb 52 Kaynak Pozisyonu

Polarity:

Esb 52 Kutuplama

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)Weld Deposit(Kg)/1Kg Consumed ElectrodeNumber of Electrodes/1Kg Weld DepositWeld Metal Deposition Rate (Kg/h)Efficiency(%)
2.00x30040-700,59890,68124
2.50x35060-1000,59730,8123
3.25x350100-1500,6471,21122
3.25x450100-1400,64331,33122
4.00x350140-1900,62311,67124
4.00x450140-1900,6231,54124
5.00x450180-2500,65152,36124
6.00x450260-3400,6993,19124

Packaging Information

Product CodeDiameter X Length (mm)Quantity per box (approx.)Box Net Weight (kg)Number Of Boxes In PackagePackage Net Weight (kg)Packaging Type
11206DJEM22.00x300131 pcs1.81018.3VAC Box
11206HJEM22.50x350105 pcs2.5615.6VAC Box
11206HQEM22.50x350105 pcs2.5615.4Cardboard Box
11206HREM22.50x350209 pcs5.0315.4Cardboard Box
11206NJEM23.25x35070 pcs2.5615.4VAC Box
11206NQEM23.25x35070 pcs2.5615.4Cardboard Box
11206NREM23.25x350140 pcs5.0315.4Cardboard Box
11206PJEM23.25x45052 pcs2.5615.6VAC Box
11206PSEM23.25x450135 pcs6.5319.9Cardboard Box
11206QJEM24.00x35048 pcs2.5615.5VAC Box
11206QQEM24.00x35048 pcs2.5615.4Cardboard Box
11206QREM24.00x35096 pcs5.0315.4Cardboard Box
11206SJEM24.00x45037 pcs2.5615.6VAC Box
11206SREM24.00x45073 pcs5.0315.4Cardboard Box
11206SSEM24.00x45095 pcs6.5319.9Cardboard Box
11206VJEM25.00x45024 pcs2.550.0VAC Box
11206VSEM25.00x45061 pcs6.5319.9Cardboard Box
11206XJFM26.00x45016 pcs2.5515.6VAC Box
11206XSEM26.00x45042 pcs6.5319.9Cardboard Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.
>It has to be dried at 350°C for 2 hours.
