ESH 180R

Standards

AWS/ASME SFA - 5.1 E7024
EN ISO 2560 - A E 38 A RR 73
TS EN ISO 2560 - A E 38 A RR 73

Properties And Applications

Heavy coated, rutile type high-efficiency electrode having a weld metal recovery of approx. 180 %. It is suited to produce long fillet welds and economically filling-up large weld sections especially in shipbuilding. Suitable to use in pre-painted plates. Relatively low current intensities and short burn-off times. Easy arc striking and restriking.

Approvals & Certificates

Materials

Width DIN
S185 - S275J2 St 33- St 44.3
P235GH, P265GH H I, H II
P295GH 17Mn4
S255N - P315N StE 255- StE 315
GE 200, GE 240 GS 38, GS 45
AH 32, EH 36
A, B, D

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMn
Weld Deposit0.070.550.80

Typical Mechanical Values of Weld Metal(%)

Test ConditionYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As welded4805502520°C → 50

Application Information

Welding Positions :
Esh 180R Kaynak Pozisyonu Esh 180R Kaynak Pozisyonu

Polarity:

Esh 180R Kutuplama Esh 180R Kutuplama

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)
2.50x35070-110
3.25x450100-170
4.00x450160-220
5.00x450220-300

Packaging Information

Product CodeDiameter x Length (mm)Quantity per BoxBox Gross Weight (kg)Boxes per Outer BoxOuter Box Gross Weight (kg)Packaging Type
11121HREM22.50x350150 pcs5.07315.40Cardboard Box
11121PSEM23.25x45095 pcs6.58319.90Cardboard Box
11121SSEM24.00x45060 pcs6.58319.90Cardboard Box
11121VSEM25.00x45038 pcs6.58319.90Cardboard Box

Storage & Re-Drying Information

>Generally not required. If required, redry for 1 hour at 110°C.
