ESR 11

Standards

AWS/ASME SFA - 5.1 E6013
EN ISO 2560 - A E 38 0 RC 11
TS EN ISO 2560 - A E 38 0 RC 11

Approvals & Certificates

Materials

Width DIN
S185 - S355J0 St 33 - St 52-3
P235GH, P265GH H I, H II
P295GH 17Mn4
P235TR2 - P355T2 St 37.4 - St 52.4
P235G1TH, P255G1TH St 35.8, St 45.8
L210 - L360NB StE 210.7 - StE 360.7
S255N - S355N StE 255- StE 355
GE 200, GE 240 GS 38, GS 45
AH 32, EH 36
A, B, D

Properties and Applications

Especially suitable for welding in sheets thinner then 5 mm, galvanized sheets and tubes, primer painted, painted and slightly rusty steels and in production of tanks and boilers, tube installations. Very easily operated in positional welding, including vertically-down. Good gap-bridging. Smooth arc, well suited for tack-welding due to its easy arc striking and re-striking properties. Possible to use equally well both with AC and DC. Welds are smooth, slightly concave and blending into base metal without undercutting. Slag is self-releasing.
Esr 11 Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMn
Weld Deposit0.100.450.70

Typical Mechanical Values of Weld Metal(%)

Test ConditionYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As welded480550250°C → 55

Application Information

Welding Positions :
Esr 11 Kaynak Pozisyonu Esr 11 Kaynak Pozisyonu Esr 11 Kaynak Pozisyonu Esr 11 Kaynak Pozisyonu Esr 11 Kaynak Pozisyonu Esr 11 Kaynak Pozisyonu Esr 11 Kaynak Pozisyonu

Polarity:

Esr 11 Kutuplama Esr 11 Kutuplama

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)
2.00x30040-60
2.00x35040-60
2.50x30060-85
2.50x35060-85
3.25x35090-130
3.25x45090-120
4.00x350130-180
4.00x450140-180
5.00x350180-230
5.00x450180-230

Packaging Information

Product CodeDiameter x Length (mm)Quantity per BoxBox Gross Weight (kg)Boxes per Outer BoxOuter Box Gross Weight (kg)Packaging Type
11100DQEM22.00x300165 pcs1.79916.30Cardboard Box
11100E9EM12.00x35015 pcs0.23307.00Blister
11100EBEM22.00x35080 pcs1.11100.00
11100EPEM22.00x35079 pcs1.051218.00Cardboard Box
11100EQEM22.00x350198 pcs2.54615.40Cardboard Box
11100EREM22.00x350395 pcs5.07315.40Cardboard Box
11100H9EM12.50x35015 pcs0.31309.60Blister
11100HBEM22.50x35054 pcs1.11100.00
11100HDEM22.50x350136 pcs2.6438.10Plastic Box
11100HEEM22.50x350272 pcs5.21315.80Plastic Box
11100HPEM22.50x35054 pcs1.051218.00Cardboard Box
11100HQEM22.50x350136 pcs2.54615.40Cardboard Box
11100HREM22.50x350272 pcs5.06315.30Cardboard Box
11100N9EM13.25x35015 pcs0.373011.40Blister
11100NBEM23.25x35034 pcs1.11100.00
11100NDEM23.25x35084 pcs2.6438.10Plastic Box
11100NEEM23.25x350168 pcs5.21315.80Plastic Box
11100NPEM23.25x35034 pcs1.051212.80Cardboard Box
11100NQEM23.25x35084 pcs2.54615.40Cardboard Box
11100NREM23.25x350168 pcs5.06315.30Cardboard Box
11100PSAM13.25x450170 pcs6.71213.60Cardboard Box
11100QBEM24.00x35022 pcs1.11100.00
11100QQEM24.00x35055 pcs2.54615.40Cardboard Box
11100QREM24.00x350109 pcs5.06315.30Cardboard Box
11100SREM24.00x45089 pcs5.07315.40Cardboard Box
11100SSEM24.00x450115 pcs6.58319.90Cardboard Box
11100TQEM25.00x35037 pcs2.54615.40Cardboard Box
11100TREM25.00x35073 pcs5.07315.40Cardboard Box
11100VQEM25.00x45028 pcs2.54615.50Cardboard Box
11100VSAM15.00x45075 pcs6.68426.90Cardboard Box
11100VSEM25.00x45074 pcs6.58319.90Cardboard Box

Storage & Re-Drying Information

>Generally not required. If required, redry for 1 hour at 110°C.
