ESR 14

Standards

AWS/ASME SFA - 5.1 E7014
EN ISO 2560 - A E 42 0 RR 12
TS EN ISO 2560 - A E 42 0 RR 12

Properties And Applications

Preferably used in mild steel fabrication, sheet metal and ornamental iron works on poor fit up joints. Due to its iron powder addition in covering, particularly suited for the welding of horizontal fillets grooves with higher speed. Suitable for all position welding except vertical-down. High current carrying capacity, low spatter. Quite, stable arc characteristics with fine and fast droplet metal transfer. Very easy arc striking and re-striking. Very smooth welds blending into base metal without undercuts. Slag is completely self-releasing. Possible to use equally well both with AC and DC.

Materials

Width DIN
S185 - S355J0 St 33 - St 52.3
P235GH, P265GH H I , H II
P295GH 17Mn4
P235TR2 - P355T2 St 37.4 - St 52.4
P235G1TH - P255G1TH St 35.8 - St 45.8
L210 - L360NB StE 210.7 - StE 360.7
S255N - S355N StE 255- StE 355
GE 200, GE 240 GS 38, GS 45
AH 32 - EH36
A, B, D

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMn
Weld Deposit0.070.450,50

Typical Mechanical Values of Weld Metal(%)

Test ConditionYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As welded480560280°C → 70-20°C → 40

Application Information

Welding Positions :
Esr 14 Kaynak Pozisyonu Esr 14 Kaynak Pozisyonu Esr 14 Kaynak Pozisyonu Esr 14 Kaynak Pozisyonu Esr 14 Kaynak Pozisyonu Esr 14 Kaynak Pozisyonu

Polarity:

Esr 14 Kutuplama Esr 14 Kutuplama

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)
2.50x35060-90
3.25x350100-140
4.00x350140-180
4.00x450140-180
5.00x350200-250
5.00x450200-240

Packaging Information

Product CodeDiameter x Length (mm)Quantity per BoxBox Gross Weight (kg)Boxes per Outer BoxOuter Box Gross Weight (kg)Packaging Type
11103HREM22.50x350229 pcs5.07315.40Cardboard Box
11103NREM23.25x350134 pcs5.07315.40Cardboard Box
11103QREM24.00x35088 pcs5.07315.40Cardboard Box
11103SSEM24.00x45095 pcs6.58319.90Cardboard Box
11103VSEM25.00x45063 pcs6.58319.90Cardboard Box

Storage & Re-Drying Information

>Generally not required. If required, redry for 1 hour at 110°C.
