ESR 35

Datasheet

Standards

AWS/ASME SFA - 5.1	E6013
EN ISO 2560 - A	E 38 2 RB 12
TS EN ISO 2560 - A	E 38 2 RB 12

Properties And Applications

Rutile-basic type coated electrode, particularly suitable for welding root passes and positional welding in fabrication of pipes, boilers and tanks. Also suitable for depositing backing-up beads in submerged arc welding. Owing to its low Si-content, weld metal is suited for subsequent galvanizing and enamelling.

Approvals & Certificates

TUV

Typical Chemical Values of Weld Metal

Type of Analysis	C	Si	Mn
Weld Deposit	0.08	0.20	0,50

Type of Analysis

Weld Deposit

0.08

0.20

0,50

Typical Mechanical Values of Weld Metal(%)

Test Condition	Yield Strength (N/mm²)	Tensile Strength (N/mm²)	Elongation A5 (%)	Charpy V-Notch Properties (J)
As welded	480	530	23	20°C → 100	0°C → 60	-20°C → 50

Test Condition

Yield Strength (N/mm²)

Tensile Strength (N/mm²)

Elongation A5 (%)

Charpy V-Notch Properties (J)

As welded

480

530

20°C → 100

0°C → 60

-20°C → 50

Application Information

Welding Positions :

Polarity:

Welding Parameters & Efficiency :

Diameter x Length (mm)	Current (A)
2.50x350	60-90
3.25x350	100-140
4.00x350	140-180
5.00x450	200-240

Packaging Information

Product Code	Diameter x Length (mm)	Quantity per Box	Box Gross Weight (kg)	Boxes per Outer Box	Outer Box Gross Weight (kg)	Packaging Type
11106HREM2	2.50x350	246 pcs	5.07	3	15.40	Cardboard Box
11106NREM2	3.25x350	147 pcs	5.07	3	15.40	Cardboard Box
11106QREM2	4.00x350	100 pcs	5.07	3	15.40	Cardboard Box
11106VSEM2	5.00x450	64 pcs	6.58	3	19.90	Cardboard Box

Storage & Re-Drying Information

>Generally not required. If required, redry for 1 hour at 110°C.
