FCO 91

Standards

AWS/ASME SFA - 5.20 E71T-11

Materials

EN DIN
S185 - S355JR St 33 , St 37-2 , St 37.4, St 44-2
E295 St 50-2
GE 200, GE 240, GE 260 GS 38, GS 45, GS 52
L210 - L390 A, B

Properties and Applications

Shielded flux cored welding wire that meets all requirements for E71T-11 classification. FCO 91 is suitable for single or multiple pass lap, fillet and butt welding on mild steels. Self-shielded flux cored wire with high build-up ratio that can be used in the top-down position in the filling and cover passes of Cross Country pipelines from API X 42 to X 70 class.Open arc (gas unshielded) flux cored welding wire that allows welding in any position. Used for outdoor construction, roofing and other assembly works, agricultural tools, equipment and repairs on vehicles. It enables single pass welding of thin sheets for overlapping and joining. Stable arc, easy weld pool control and slag removal.
Fco 91 Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMnAl
Weld Deposit0.10.180.801.50

Typical Mechanical Values of Weld Metal(%)

Test ConditionYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)
As welded51564522

Application Information

Welding Positions :
Fco 91 Kaynak Pozisyonu Fco 91 Kaynak Pozisyonu Fco 91 Kaynak Pozisyonu Fco 91 Kaynak Pozisyonu Fco 91 Kaynak Pozisyonu Fco 91 Kaynak Pozisyonu

Polarity:

Fco 91 Kutuplama DC(-)

Welding Parameters & Efficiency :

Packaging Information

Product CodeDiameter (mm)Weight Of The Box (kg)Boxes Per PackageWeight Of The PackagePackaging Type
31202EIBM21.2015.0116.0Plastic Spool (D300) VAC
31202ELBM21.2015.0116.0Wire Basket Spool (K300MS)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
