FCW 11

Standards

AWS/ASME SFA - 5.20 E71T-1C
EN ISO 17632 - A T46 2 P C 1
TS EN ISO 17632 - A T46 2 P C 1

Approvals & Certificates

Materials

Width DIN
S185 - S355J0 St 33- St 52.3
P235TR2 - P355T2 St 37.4 - St 52.4
P235G1TH, P255G1TH St 35.8 - St 45.8
P295GH 17Mn4
P235GH, P265GH H I, H II
S255N - S420N StE 255 - StE 420
L210 - L415NB StE 210.7 - StE 415.7
L290MB - L450MB StE 290.7 TM - StE 445.7 TM
GE 200, GE 240 GS 38, GS 45
AH 32 - EH 36
A, B, D, E
X42 - X65

Properties and Applications

Rutile type flux cored wire with fast-freezing slag. Especially designed for welding with CO2 (carbondioxide) gas, in shipbuilding and steel construction. Owing to its easily controllable weld pool, electrode is well suited for positional welding with higher currents, resulting in increased deposition rates. Particularly suited for welding in the horizontal-vertical position, e.g. in tank welding. Electrode of 1.2 mm in diameter is also suitable for vertical-down welding. Low spatter loss, easy slag removal, finely ripped pore-free welds blending into base metal without undercut.
Fcw 11 Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMn
Weld Deposit0.040.401.50

Typical Mechanical Values of Weld Metal(%)

Test ConditionProtection GasYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As weldedC150056025-20°C → 70

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - C1 (%100 CO2) .

Application Information

Welding Positions :
Fcw 11 Kaynak Pozisyonu Fcw 11 Kaynak Pozisyonu Fcw 11 Kaynak Pozisyonu Fcw 11 Kaynak Pozisyonu Fcw 11 Kaynak Pozisyonu Fcw 11 Kaynak Pozisyonu Fcw 11 Kaynak Pozisyonu

Polarity:

Fcw 11 Kutuplama

Protection Gas:

C1

Welding Parameters & Efficiency :

Diameter (mm)Current (A)
1.0060-130
1.20180-240
1.60250-400
2.40400-550

Packaging Information

Product CodeDiameter (mm)Quantity per BoxBox Gross Weight (kg)Boxes per Outer BoxOuter Box Gross Weight (kg)Packaging Type
31001DCAM21.005 kg5.4015.40Plastic Spool (D200) VAC
31001DIAM21.0015 kg16.00116.00Plastic Spool (D300) VAC
31001ECAM21.205 kg5.4015.40Plastic Spool (D200) VAC
31001ECAM51.205 kg5.4015.40Plastic Spool (D200) VAC
31001EIAM21.2015 kg16.00116.00Plastic Spool (D300) VAC
31001GIAM21.6015 kg16.00116.00Plastic Spool (D300) VAC

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
