FCW 15A

Standards

AWS/ASME SFA - 5.20 E71T-1C-J H4
EN ISO 17632 - A T 42 4 P C1 1 H5
TS EN ISO 17632 - A T 42 4 P C1 1 H5

Materials

EN DIN
S185 - S355J0 St 33- St 52.3
P235TR2 - P355T2 St 37.4 - St 52.4
P235G1TH, P255G1TH St 35.8 - St 45.8
P295GH 17Mn4
P235GH, P265GH H I, H II
S255N - S420N StE 255 - StE 420
L210 - L415NB StE 210.7 - StE 415.7
L290MB - L450MB StE 290.7 TM - StE 445.7 TM
GE 200, GE 240 GS 38, GS 45
AH 32 - EH 36
A, B, D, E
X42 - X65

Properties and Applications

Rutile type flux cored wire with very fast-freezing slag. Especially designed for welding with CO2 (carbondioxide) gas, in shipbuilding and steel construction industries. Weld metal has high charpy impact strength and toughness down to -40°C. Owing to it's very easily controllable weld pool, well suited for positional welding at higher currents, resulting in increased deposition rates. 1.20 mm and lower diameter wires are very suitable for vertical-down welding. Low spatter loss, finely ripped pore-free welds blending into base metal without undercut. Slag removal is easy in fillet welds and narrow grooves.
Fcw 15A Sert Dolgu

Application Information

Welding Positions :
Fcw 15A Kaynak Pozisyonu Fcw 15A Kaynak Pozisyonu Fcw 15A Kaynak Pozisyonu Fcw 15A Kaynak Pozisyonu Fcw 15A Kaynak Pozisyonu Fcw 15A Kaynak Pozisyonu Fcw 15A Kaynak Pozisyonu

Polarity:

Fcw 15A Kutuplama DC(+)

Protection Gas:

C1

Packaging Information

Product CodeDiameter (mm)Weight Of The Box (kg)Number Of Boxes Per PackageWeight Of The PackagePackaging Type
31008EIBM51.2015.0116.0Plastic Spool (D300) VAC

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
