FCW 16

Standards

AWS/ASME SFA - 5.20 E71T-9C J
AWS/ASME SFA - 5.20 E71T-1C J
EN ISO 17632 - A T46 4 P C1
TS EN ISO 17632 - A T46 4 P C1

Properties And Applications

Rutile type flux cored wire, which has high strength and designed for welding in all position. Suitable for welding fine grained structural steels and high stregth shipbuilding steels in all position, where low heat input and less deformation are required. Has a stable and quite arc. Good gap-bridging property, low spatter loss, easy slag removal even in narrow grooves. Finely ripped pore-free welds blending into base metal without undercut.

Approvals & Certificates

Materials

Width DIN
S185 - S355J0 St 33- St 52.3
P235TR2 - P355T2 St 37.4 - St 52.4
P235G1TH, P255G1TH St 35.8 - St 45.8
P295GH 17Mn4
P235GH, P265GH H I, H II
S255N - S420N StE 255 - StE 420
L210 - L415NB StE 210.7 - StE 415.7
L290MB - L450MB StE 290.7 TM - StE 445.7 TM
GE 200, GE 240 GS 38, GS 45
AH 32, EH 36
A, B, D, E
X42 - X65

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMnNi
Weld Deposit0.050.301.450.40

Typical Mechanical Values of Weld Metal(%)

Test ConditionProtection GasYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As weldedC151058027-40°C → 70

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - C1 (%100 CO2) .

Application Information

Welding Positions :
Fcw 16 Kaynak Pozisyonu Fcw 16 Kaynak Pozisyonu Fcw 16 Kaynak Pozisyonu Fcw 16 Kaynak Pozisyonu Fcw 16 Kaynak Pozisyonu Fcw 16 Kaynak Pozisyonu Fcw 16 Kaynak Pozisyonu

Polarity:

Fcw 16 Kutuplama

Protection Gas:

C1

Welding Parameters & Efficiency :

Diameter (mm)Current (A)
1.0080-120
1.20120-180
1.60250-440

Packaging Information

Product CodeDiameter (mm)Quantity per BoxBox Gross Weight (kg)Boxes per Outer BoxOuter Box Gross Weight (kg)Packaging Type
31005DIAM21.0015 kg16.00116.00Plastic Spool (D300) VAC
31005EIAM21.2015 kg16.00116.00Plastic Spool (D300) VAC
31005GIAM21.6015 kg16.00116.00Plastic Spool (D300) VAC

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
