FCW 30

Standards

AWS/ASME SFA - 5.20 E70T-5C H4
AWS/ASME SFA - 5.20 E70T-5M H4
EN ISO 17632 - A T42 4 B M 3 H5
EN ISO 17632 - A T42 4 B C 3 H5
TS EN ISO 17632 - A T42 4 B M 3 H5
TS EN ISO 17632 - A T42 4 B C 3 H5

Approvals & Certificates

Materials

Width DIN
S185 - S355J0 St 33- St 52.3
P235TR2 - P355T2 St 37.4 - St 52.4
P235G1TH, P255G1TH St 35.8 - St 45.8
E295 St 50.2
P295GH, P355GH 17Mn4, 19Mn5
P235GH, P265GH H I, H II
S255N - S355N StE 255 - StE 355
L210 - L360NB StE 210.7 - StE 360.7
GE 200, GE 240, GE 260 GS-38, GS-45, GS-52
A, B, D, E

Properties and Applications

Basic type flux cored wire for welding thick steel sections and dynamically loaded structures, where high toughness is required. Provides high mechanical properties and high crack resistant weld metal. Suitable to welding of boiler, tank, pressure vessel, heavy machine production and heavy constructions. Weld are metallurgically clean and are of X-ray quality. Suitable for welding high carbon steels and buffer application on worn parts before hardfacing.
Fcw 30 Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisProtection GasCSiMn
Weld DepositC10.040,501.45
Weld DepositM210.040.601.50

Typical Mechanical Values of Weld Metal(%)

Test ConditionProtection GasYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As weldedC145052029-40°C → 100
As weldedM2151060025-40°C → 90

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - C1 (%100 CO2) .

Application Information

Welding Positions :
Fcw 30 Kaynak Pozisyonu Fcw 30 Kaynak Pozisyonu

Polarity:

Fcw 30 Kutuplama

Protection Gas:

M21 C1

Welding Parameters & Efficiency :

Diameter (mm)Current (A)
1.0060-130
1.20120-180
1.60250-400
2.40400-550

Packaging Information

Product CodeDiameter (mm)Quantity per BoxBox Gross Weight (kg)Boxes per Outer BoxOuter Box Gross Weight (kg)Packaging Type
31030DIAM21.0015 kg16.00116.00Plastic Spool (D300) VAC
31030EIAM21.2015 kg16.00116.00Plastic Spool (D300) VAC
31030GIAM21.6015 kg16.00116.00Plastic Spool (D300) VAC
31030IIAM22.4015 kg16.00116.00Plastic Spool (D300) VAC
31030IXAM22.4025 kg25.80125.80Wire Basket Spool (K435)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
