MAL 1100

Datasheet

Standards

AWS/ASME SFA - 5.10	~ER1100
AWS/ASME SFA - 5.10	ER1070
EN ISO 18273	S Al 1070 (Al99.7)
TS 6204 EN ISO 18273	S Al 1070 (Al99.7)
DIN M. No.	3.0259

Materials

DIN	Material
Al 99.0	3.0205
Al 99.5	3.0255
Al 99.7	3.0275
Al 99.8	3.0285

Properties and Applications

Aluminium welding wire electrode for GMA (MIG) welding of pure aluminium base metals. Exhibits high corrosion resistance and has high electrical conductivity. Has color match with pure aluminium base metals.

Typical Chemical Features of the Welding Wire

Type of Analysis	Al
Welding Wire	99.50

Type of Analysis

Welding Wire

99.50

Typical Mechanical Values of Weld Metal(%)

Test Condition	Protection Gas	Tensile Strength (N/mm²)	% 0,2 Yield Strength (N/mm²)	Elongation A5 (%)
As welded	I1	65	20	35

Test Condition

Protection Gas

Tensile Strength (N/mm²)

% 0,2 Yield Strength (N/mm²)

Elongation A5 (%)

As welded

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - I1 (%100 Ar) .

Application Information

Welding Positions :

Polarity:

DC(+)

Protection Gas:

I3 I1 I2

Welding Parameters & Efficiency :

Packaging Information

Product Code	Diameter (mm)	Weight Of The Box (kg)	Number Of Boxes Per Package	Weight Of The Package	Packaging Type
24000HJAM2	2.00	6.5	1	7.1	Wire Basket Spool (K300MS)
24000HJAM5	2.00	7.0	1	7.6	Wire Basket Spool (K300MS)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
