MAL 5183

Datasheet

Standards

AWS/ASME SFA - 5.10	ER5183
EN ISO 18273	S Al 5183 (AlMg4.5Mn0.7(A))
TS 6204 EN ISO 18273	S Al 5183 (AlMg4.5Mn0.7(A))
DIN M. No.	3.3548

Properties And Applications

5% Magnesium and manganese containing aluminium alloy welding wire for GMA (MIG) welding of Al-alloys with high tensile strenght requirements. Suitable for welding Al-Mg alloys and Al-Mg-Mn alloys.

Materials

DIN	Material
AlMgSi 1	3.2315
G-AlMg 5	3.3561
G-AlMg 3 Cu	3.3543
G-AlMg 5 Si	3.3261
G-AlMg 10	3.3591
AlZn 4.5 Mg 1	3.4335
G-AlMg 3 Si	3.3241
AlMg 3	3.3535
G-AlMg 3	3.3541
AlMg 5	3.3555
AlMg 4.5 Mn	3.3547

Typical Chemical Features of the Welding Wire

Type of Analysis	Mn	Ti	Al	Mg
Welding Wire	0.60	0.10	94.55	4.75

Type of Analysis

Welding Wire

0.60

0.10

94.55

4.75

Typical Mechanical Values of Weld Metal(%)

Test Condition	Protection Gas	Tensile Strength (N/mm²)	% 0,2 Yield Strength (N/mm²)	Elongation A5 (%)
As welded	I1	270	125	23

Test Condition

Protection Gas

Tensile Strength (N/mm²)

% 0,2 Yield Strength (N/mm²)

Elongation A5 (%)

As welded

270

125

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - I1 (%100 Ar) .

Application Information

Welding Positions :

Polarity:

Protection Gas:

I3 I1 I2

Welding Parameters & Efficiency :

Diameter (mm)
1.00
1.20

Diameter (mm)

1.00

1.20

Packaging Information

Product Code	Diameter (mm)	Quantity per Box	Kutu Brüt Ağırlığı (kg)	Boxes per Outer Box	Koli Ağırlığı (kg)	Packaging Type
24003DJAM5	1.00	7 kg	7.60	1	7.60	Wire Basket Spool (K300MS)
24003EJAM2	1.20	7 kg	7.10	1	7.10	Wire Basket Spool (K300MS)
24003EJAM5	1.20	7 kg	7.60	1	7.60	Wire Basket Spool (K300MS)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
