MAL 5356

Standards

AWS/ASME SFA - 5.10 ER5356
EN ISO 18273 S Al 5356 (AlMg5Cr(A))
TS 6204 EN ISO 18273 S Al 5356 (AlMg5Cr(A))
DIN M. No. 3.3556

Properties And Applications

5% Magnesium containing aluminium welding wire for GMA (MIG) welding of Al-Mg alloys and Al-Mg-Si alloys. Very good corrosion resistance especially in sea water and gives excellent ductility.

Materials

DIN Material
AlMgSi 1 3.2315
G-AlMg 5 3.3561
G-AlMg 5 Si 3.3261
AlZn 4.5 Mg 1 3.4335
G-AlMg 3 Si 3.3241
AlMg 2 Mn 0.8 3.3527
AlMg 3 3.3535
G-AlMg 3 3.3541
AlMg 5 3.3555
AlMg 4.5 3.3345
AlMg1 3.3315
Al Mg 1.5 3.3316
Al Mg 1.8 3.3326
Al Mg 2.5 3.3523

Typical Chemical Features of the Welding Wire

Type of AnalysisCrAlMg
Welding Wire0.1095.154.75

Typical Mechanical Values of Weld Metal(%)

Test ConditionProtection GasTensile Strength (N/mm²)% 0,2 Yield Strength (N/mm²)Elongation A5 (%)
As weldedI124011026

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - I1 (%100 Ar) .

Application Information

Welding Positions :
Mal 5356 Kaynak Pozisyonu Mal 5356 Kaynak Pozisyonu Mal 5356 Kaynak Pozisyonu Mal 5356 Kaynak Pozisyonu Mal 5356 Kaynak Pozisyonu Mal 5356 Kaynak Pozisyonu Mal 5356 Kaynak Pozisyonu

Polarity:

Mal 5356 Kutuplama

Protection Gas:

I3 I1 I2

Welding Parameters & Efficiency :

Diameter (mm)
0.80
1.00
1.20

Packaging Information

Product CodeDiameter (mm)Quantity per BoxBox Gross Weight (kg)Boxes per Outer BoxOuter Box Gross Weight (kg)Packaging Type
24004BBAM20.802 kg2.3012.30Plastic Spool (D200)
24004BJAM50.807 kg7.6017.60Wire Basket Spool (K300MS)
24004DBAM21.002 kg2.3012.30Plastic Spool (D200)
24004DJAM21.007 kg7.1017.10Wire Basket Spool (K300MS)
24004DJAM51.007 kg7.6017.60Wire Basket Spool (K300MS)
24004EJAM21.207 kg7.1017.10Wire Basket Spool (K300MS)
24004EJAM51.207 kg7.6017.60Wire Basket Spool (K300MS)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
