MAL 5556

Datasheet

Standards

AWS/ASME SFA - 5.10	ER5556
EN ISO 18273	S Al 5556 (AlMg5Mn1Ti(A))
TS 6204 EN ISO 18273	S Al 5556 (AlMg5Mn1Ti(A))
DIN M. No.	~3.3548

Approvals & Certificates

CE-DoP

Properties and Applications

5% Magnesium containing aluminium welding wire for GMA (MIG) welding of Al-Mg alloys and Al-Mg-Zn alloys. Have a good corrosion resistance especially in sea water and gives excellent ductility.

Typical Chemical Features of the Welding Wire(%)

Type of Analysis	Si	Mn	Cr	Ti	Al	Cu	Zn	Fe	Mg
Welding Wire	0.05	0.65	0.07	0.07	94.13	0.01	0.006	0.11	4.90

Type of Analysis

Welding Wire

0.05

0.65

0.07

94.13

0.01

0.006

0.11

4.90

Typical Mechanical Values of Weld Metal

Test Condition	Protection Gas	Yield Strength (N/mm²)	Tensile Strength (N/mm²)	Elongation A5 (%)
As welded	I1	130	290	28

Test Condition

Protection Gas

Yield Strength (N/mm²)

Tensile Strength (N/mm²)

Elongation A5 (%)

As welded

130

290

* Chemical compositon and mechanical properties are valid when using shielding gas .

Application Information

Welding Positions :

Polarity:

DC(+)

Protection Gas:

I3 I1 I2

Welding Parameters & Efficiency :

Packaging Information

Product Code	Diameter (mm)	Weight Of The Box (kg)	Boxes Per Package	Weight Of The Package	Packaging Type
24005DJAM5	1.00	7.0	1	7.6	Wire Basket Spool (K300MS)
24005EJAM5	1.20	7.0	1	7.6	Wire Basket Spool (K300MS)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
