MG 1

Datasheet

Standards

AWS/ASME SFA - 5.18	ER70S-3
EN ISO 14341 - A	G 38 3 C1 2Si
EN ISO 14341 - A	G 38 3 M21 2Si
TS EN ISO 14341 - A	G 38 3 M21 2Si
TS EN ISO 14341 - A	G 38 3 C1 2Si
DIN M. No.	1.5112

Properties And Applications

Unalloyed wire electrode for GMA (MIG/MAG) welding of unalloyed steels by using CO₂ or mixed gases, depending on thickness of the base metal. Characterized by a reduced slag formation and smooth welding deposit. Particularly suitable for welding of galvanized and pre-paint steels, welding unalloyed steels in pipe-lines, boilers and tank construction. Suitable also welding thin metal plates and repair welds. A thin and homogeneous copper coating increases electrical conducvitiy and protects the wire from using.

Materials

Width	DIN
S185 - S275T1	St 33 - St 44.0
P235G1TH - P25G1TH5	St 35.8 - St 45.8
P235GH, P265GH	H I, H II
-	A,B, D, E

Typical Chemical Features of the Welding Wire

Type of Analysis	C	Si	Mn
Welding Wire	0.07	0.70	1.25

Type of Analysis

Welding Wire

0.07

0.70

1.25

Typical Mechanical Values of Weld Metal(%)

Test Condition	Protection Gas	Yield Strength (N/mm²)	Tensile Strength (N/mm²)	Elongation A5 (%)	Charpy V-Notch Properties (J)
As welded	C1	400	470	30	-30°C → 100
As welded	M21	420	520	30	-30°C → 80

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - C1 (%100 CO2) ve M21 (Ar + %20 CO2) .

Application Information

Welding Positions :

Polarity:

Protection Gas:

M20 M24 M26 M21 C1

Welding Parameters & Efficiency :

Diameter (mm)
0.80
1.00
1.20
1.60

Diameter (mm)

0.80

1.00

1.20

1.60

Packaging Information

Product Code	Diameter (mm)	Quantity per Box	Kutu Brüt Ağırlığı (kg)	Boxes per Outer Box	Koli Ağırlığı (kg)	Packaging Type
21001B0GM2	0.80	60 kg	64.00	1	64.00	Fiber Drum
21001B1GM2	0.80	250 kg	257.50	1	257.50	Fiber Drum
21001BAKM2	0.80	1 kg	1.10	14	15.70	Plastic Spool (D100)
21001BHAM2	0.80	15 kg	15.80	1	0.00	Plastic Spool (D300)
21001BJAM2	0.80	15 kg	15.70	1	15.70	Wire Basket Spool (K300MS)
21001D1GM2	1.00	250 kg	257.50	1	257.50	Fiber Drum
21001DBAM2	1.00	5 kg	5.30	1	5.30	Plastic Spool (D200)
21001DHAM2	1.00	15 kg	15.80	1	15.20	Plastic Spool (D300)
21001DJAM2	1.00	15 kg	15.70	1	15.70	Wire Basket Spool (K300MS)
21001E1GM2	1.20	250 kg	257.50	1	257.50	Fiber Drum
21001EJAM2	1.20	15 kg	15.70	1	15.70	Wire Basket Spool (K300MS)
21001EJBM2	1.20	15 kg	15.70	1	15.70	Wire Basket Spool (K300MS)
21001GJAM2	1.60	15 kg	15.70	1	15.70	Wire Basket Spool (K300MS)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
