MG 102

Datasheet

Standards

AWS/ASME SFA - 5.18	ER70S-2
EN ISO 14341 - A	G 42 3 C1 2Ti
EN ISO 14341 - A	G 42 3 M21 2Ti
TS EN ISO 14341 - A	G 42 3 C1 2Ti
TS EN ISO 14341 - A	G 42 3 M21 2Ti

Properties And Applications

Micro-alloyed wire electrode for GMA (MIG/MAG) welding of unalloyed and low-alloy steels. Characterized by a reduced slag formation and smooth welding deposit. Due to its Al and Ti micro-alloy content, particularly suitable for single pass welding of galvanized, pre-painted, rusty and dirty steels, welding low alloy steels in pipe-lines, boilers and tank production. Suitable also welding in thin metal plates and repair welds. CO₂ or mixed shielding gases can be used depending on the thickness of the base metal. A thin and homogeneous copper coating increases electrical conductivity and protects the wires from rusting.

Approvals & Certificates

CWB

Materials

Width	DIN
S185 - P275T1	St 33 - St 44.0
P235G1TH - P265G1TH	St 35.8 - St 45.8
P235GH, P265GH	H I, H II
-	A, B, D, E

Typical Chemical Features of the Welding Wire

Type of Analysis	C	Si	Mn	Ti	Al	Zr
Welding Wire	0.04	0,50	1.10	0.13	0.10	0.08

Type of Analysis

Welding Wire

0.04

0,50

1.10

0.13

0.10

0.08

Typical Mechanical Values of Weld Metal(%)

Test Condition	Protection Gas	Yield Strength (N/mm²)	Tensile Strength (N/mm²)	Elongation A5 (%)	Charpy V-Notch Properties (J)
As welded	C1	460	530	25	-30°C → 60

Test Condition

Protection Gas

Yield Strength (N/mm²)

Tensile Strength (N/mm²)

Elongation A5 (%)

Charpy V-Notch Properties (J)

As welded

460

530

-30°C → 60

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - C1 (%100 CO2) .

Application Information

Welding Positions :

Polarity:

Protection Gas:

M20 M21 C1

Welding Parameters & Efficiency :

Diameter (mm)
0.60
0.80
0.90
1.00
1.20
1.60

Diameter (mm)

0.60

0.80

0.90

1.00

1.20

1.60

Packaging Information

Product Code	Diameter (mm)	Quantity per Box	Kutu Brüt Ağırlığı (kg)	Boxes per Outer Box	Koli Ağırlığı (kg)	Packaging Type
21000ABAM2	0.60	5 kg	5.30	1	5.30	Plastic Spool (D200)
21000AJAM2	0.60	12 kg	12.70	1	12.70	Wire Basket Spool (K300MS)
21000B0GM2	0.80	60 kg	64.00	1	64.00	Fiber Drum
21000B1GM2	0.80	250 kg	257.50	1	257.50	Fiber Drum
21000BBAM2	0.80	5 kg	5.30	1	5.30	Plastic Spool (D200)
21000BJAM2	0.80	15 kg	15.70	1	15.70	Wire Basket Spool (K300MS)
21000CSAM2	0.90	20 kg	20.90	1	20.90	Plastic Spool (D300)
21000D1JM2	1.00	250 kg	257.50	1	257.50	Fiber Drum
21000DBAM2	1.00	5 kg	5.30	1	5.30	Plastic Spool (D200)
21000DJAM2	1.00	15 kg	15.70	1	15.70	Wire Basket Spool (K300MS)
21000E0GM2	1.20	60 kg	64.00	1	64.00	Fiber Drum
21000E1HM2	1.20	250 kg	257.50	1	257.50	Fiber Drum
21000EJAM2	1.20	15 kg	15.70	1	15.70	Wire Basket Spool (K300MS)
21000GJAM2	1.60	15 kg	15.70	1	15.70	Wire Basket Spool (K300MS)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
