MG 150

Standards

AWS/ASME SFA - 5.28 ER80S-Ni1
EN ISO 14341 - A G 50 6 M21 3Ni1
TS EN ISO 14341 - A G 50 6 M21 3Ni1

Properties And Applications

Low alloyed wire electrode for GMA (MIG/MAG) welding of steels, which are subjected to operating temperatures down to -60°C. Weld metal has high strength and high toughness. Suitable to use in petrochemical, chemical, oil/gas industries and off-shore platforms, especially welding of pipes, boilers, tanks and valves, pumps which are made of cast or forged steels.

Materials

Width DIN ASTM API
11MnNi5-3
13MnNi6-3
S275NL- S460NL TStE 285 - TStE 460
S275ML - S460ML
P275NL2 - P460NL2 EStE 285 - EStE 460
P355ML2 - P460ML2
A333 - A334 (Gr 1-6)
A350 (Gr LF2-LF6)
A352 (Gr LCB-LCC)
L450MB X65

Typical Chemical Features of the Welding Wire

Type of AnalysisCSiMnNi
Welding Wire0.090,501.050.90

Typical Mechanical Values of Weld Metal(%)

Test ConditionProtection GasYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As weldedM2148057028-60°C → 60

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - M21 (Ar + %15-25 CO2) .

Application Information

Welding Positions :
Mg 150 Kaynak Pozisyonu Mg 150 Kaynak Pozisyonu Mg 150 Kaynak Pozisyonu Mg 150 Kaynak Pozisyonu Mg 150 Kaynak Pozisyonu Mg 150 Kaynak Pozisyonu Mg 150 Kaynak Pozisyonu

Polarity:

Mg 150 Kutuplama

Protection Gas:

M21

Welding Parameters & Efficiency :

Diameter (mm)
0.80
1.00
1.20

Packaging Information

Product CodeDiameter (mm)Quantity per BoxBox Gross Weight (kg)Boxes per Outer BoxOuter Box Gross Weight (kg)Packaging Type
22010BJAM20.8015 kg15.70115.70Wire Basket Spool (K300MS)
22010DJAM21.0015 kg15.70115.70Wire Basket Spool (K300MS)
22010EJAM21.2015 kg15.70115.70Wire Basket Spool (K300MS)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
