MG 150W

Datasheet

Standards

AWS/ASME SFA - 5.28 ER80S-G
EN ISO 14341 - A G 42 2 M21 Z2NiCu
TS EN ISO 14341 - A G 42 2 M21 Z2NiCu

Properties And Applications

Low-alloyed GMA (MIG/MAG) welding wire designed for welding of weathering steels (like COR-TEN) with high mechanical properties. Due to nickel and copper alloys, it provides higher corrosion resistance then carbon steels. Suitable for welding in steel construction manufacturing such as bridge, stadium and steel construction.

Materials

Width DIN ASTM API
11MnNi5-3
13MnNi6-3
S275NL- S460NL TStE 285 - TStE 460
S275ML - S460ML
P275NL2 - P460NL2 EStE 285 - EStE 460
P355ML2 - P460ML2
A333 - A334 (Gr 1-6)
A350 (Gr LF2-LF6)
A352 (Gr LCB-LCC)
L450MB X65

Typical Chemical Features of the Welding Wire

Type of AnalysisCSiMnNiCu
Welding Wire0.090.801.400.800.40

Typical Mechanical Values of Weld Metal(%)

Test ConditionProtection GasYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As weldedM2147060027-20°C → 47

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - M21 (Ar + %15-25 CO2) .

Application Information

Welding Positions :
Mg 150W Kaynak Pozisyonu Mg 150W Kaynak Pozisyonu Mg 150W Kaynak Pozisyonu Mg 150W Kaynak Pozisyonu Mg 150W Kaynak Pozisyonu Mg 150W Kaynak Pozisyonu Mg 150W Kaynak Pozisyonu

Polarity:

Mg 150W Kutuplama

Protection Gas:

M21

Welding Parameters & Efficiency :

Diameter (mm)
1.00
1.20

Packaging Information

Product CodeDiameter (mm)Quantity per BoxKutu Brüt Ağırlığı (kg)Boxes per Outer BoxKoli Ağırlığı (kg)Packaging Type
22012DJAM21.0015 kg15.70115.70Wire Basket Spool (K300MS)
22012EJAM21.2015 kg15.70115.70Wire Basket Spool (K300MS)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
