MG 182

Datasheet

Standards

AWS/ASME SFA - 5.28	ER110S-G
EN ISO 16834 - A	G 69 6 M21 Mn4Ni1,5CrMo
TS EN ISO 16834 - A	G 69 6 M21 Mn4Ni1,5CrMo

Properties and Applications

Low alloyed wire electrode for GMA (MIG/MAG) welding of fine grained and high strength steels with yield strength of up to 690 N/mm2. Weld metal exhibits good toughness properties down to -60°C. Especially used in high strength pipe-lines, earthmoving and mining equipments, trucks, mobile cranes, concrete pumps cranes and lift productions.

Mg 182 Sert Dolgu

Typical Chemical Features of the Welding Wire

Type of Analysis

C

Si

Mn

Cr

Ni

Mo

Ti

Welding Wire

0.09

0.55

1.55

0.25

1.35

0.25

0.07

Typical Mechanical Values of Weld Metal(%)

Test Condition

Protection Gas

Yield Strength (N/mm²)

Tensile Strength (N/mm²)

Elongation A5 (%)

Charpy V-Notch Properties (J)

As welded

M21

750

820

20

-60°C → 55

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - M21 (%82 Ar + %18 CO2) .

Application Information

Welding Positions :

Mg 182 Kaynak Pozisyonu

Mg 182 Kaynak Pozisyonu

Mg 182 Kaynak Pozisyonu

Mg 182 Kaynak Pozisyonu

Mg 182 Kaynak Pozisyonu

Mg 182 Kaynak Pozisyonu

Mg 182 Kaynak Pozisyonu

Polarity:

Mg 182 Kutuplama

Protection Gas:

M21

Welding Parameters & Efficiency :

Packaging Information

Product Code	Diameter (mm)	Quantity per box (approx.)	Box Net Weight (kg)	Number Of Boxes In Package	Package Net Weight (kg)	Packaging Type
22022DJAM2	1.00	15 kg	15.0	1	15.7	Wire Basket Spool (K300MS)
22022EJAM2	1.20	15 kg	15.0	1	15.7	Wire Basket Spool (K300MS)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
