MG 183

Datasheet

Standards

AWS/ASME SFA - 5.28	ER100S-G
AWS/ASME SFA - 5.28	ER110S-G
EN ISO 16834 - A	G 69 4 M21 Mn3Ni1CrMo
TS EN ISO 16834 - A	G 69 4 M21 Mn3Ni1CrMo

Properties And Applications

Low alloyed wire electrode for GMA (MIG/MAG) welding of fine grained and high strength steels with yield strength of up to 690 N/mm2. Weld metal exhibits good toughness properties down to -40°C. Especially used in high strength pipe-lines, earthmoving and mining equipments, trucks, mobile cranes, concrete pumps cranes and lift productions.

Materials

Width	ASTM
S500Q - S690Q
S500QL - S690QL
P500Q - P690Q
P500QL1 - P690QL1
	HY80
	Q1(N)
	HY100
	A514

Typical Chemical Features of the Welding Wire

Type of Analysis	C	Si	Mn	Cr	Ni	Mo
Welding Wire	0.09	0.55	1.55	0.30	1.40	0.25

Type of Analysis

Welding Wire

0.09

0.55

1.55

0.30

1.40

0.25

Typical Mechanical Values of Weld Metal(%)

Test Condition	Protection Gas	Yield Strength (N/mm²)	Tensile Strength (N/mm²)	Elongation A5 (%)	Charpy V-Notch Properties (J)
As welded	M21	710	780	19	-40°C → 65

Test Condition

Protection Gas

Yield Strength (N/mm²)

Tensile Strength (N/mm²)

Elongation A5 (%)

Charpy V-Notch Properties (J)

As welded

M21

710

780

-40°C → 65

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - M21 (%82 Ar + %18 CO2) .

Application Information

Welding Positions :

Polarity:

Protection Gas:

M21

Welding Parameters & Efficiency :

Diameter (mm)
1.00
1.20
1.60

Diameter (mm)

1.00

1.20

1.60

Packaging Information

Product Code	Diameter (mm)	Quantity per Box	Kutu Brüt Ağırlığı (kg)	Boxes per Outer Box	Koli Ağırlığı (kg)	Packaging Type
22023DJAM2	1.00	15 kg	15.70	1	15.70	Wire Basket Spool (K300MS)
22023E2GM2	1.20	400 kg	416.00	1	416.00	Fiber Drum
22023EJAM2	1.20	15 kg	15.70	1	15.70	Wire Basket Spool (K300MS)
22023GJAM2	1.60	15 kg	15.70	1	15.70	Wire Basket Spool (K300MS)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
