MNI 425

Standards

AWS/ASME SFA - 5.14 ERNiCrMo-3
EN ISO 18274 - A SNi 6625 (NiCr22Mo9Nb)
TS EN ISO 18274 - A SNi 6625 (NiCr22Mo9Nb)
DIN M. No. 2.4831

Properties and Applications

Ni-Cr-Mo alloyed GMA (MIG) welding wire, depositing Ni-22Cr9Mo3,5Nb weld metal. Used for welding of highly corrosion resistant Ni-Cr-Mo alloys, like Alloy 625, 825 and similar alloys. Due to it's good cryogenic toughness down to -196°C, preferred for welding of cyrogenic nickel alloys, e.g. X1NiCrMoCuN25-20-7. In sulphur free atmospheres the weld metal is non-scaling up to 1200°C, in sulphurous atmospheres the weld metal can be used in service temperatures up to 500°C. It is also highly resistant stress corrosion cracking and pitting corrosion in phosphoric acid, organic acids, sea water and polluting environments. Weld metal is insensitive to cracking and very resistant to thermal shocks. Used for joining of dissimilar nickel alloys, joining dissimilar stainless steels, low alloyed steels to stainless steels or to nickel alloys, buffering of difficult to weld steels and repair welding of them.Stick Electrode : ENI 425TIG Welding Rod: TNI 425
Mni 425 Sert Dolgu

Typical Chemical Features of the Welding Wire

Type of AnalysisCSiMnCrNiMoNbTiFe
Welding Wire0.010.050.0522.2065.008.703.650.200.14

Typical Mechanical Values of Weld Metal(%)

Test ConditionProtection GasYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As weldedI14607204020°C → 110-196°C → 100

* Chemical compositon and mechanical properties are valid when using shielding gas .

Application Information

Welding Positions :
Mni 425 Kaynak Pozisyonu Mni 425 Kaynak Pozisyonu Mni 425 Kaynak Pozisyonu Mni 425 Kaynak Pozisyonu Mni 425 Kaynak Pozisyonu Mni 425 Kaynak Pozisyonu Mni 425 Kaynak Pozisyonu

Polarity:

Mni 425 Kutuplama

Protection Gas:

I1

Welding Parameters & Efficiency :

Packaging Information

Product CodeDiameter (mm)Quantity per box (approx.)Box Net Weight (kg)Number Of Boxes In PackagePackage Net Weight (kg)Packaging Type
26004EJAM21.2015 kg15.0115.7Wire Basket Spool (K300MS)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
