SF 414

Standards

EN ISO 14174 S A AB 1
TS EN ISO 14174 S A AB 1

Properties and Applications

Alumina- basic type, agglomerated submerged arc welding flux, which is designed for single or multi pass welding of butt and fillet joints in high strength steels. Especially designed for thick section welding in steel construction, wind tower, boiler and pressure vessel production. Provides high toughness values down to -50°C. Due to it's high current carrying capacity and good operating characteristics both on alternative and direct currents, possible to use in one side welding and two side welding processes by single or multi-wires (tandem/twin). Has high penetration and smooth weld beads with easy slag removal in fillet and V-groves.
Sf 414 Sert Dolgu

Typical Chemical Values of Weld Metal

Welding WireType of AnalysisCSiMnMo
SW 702Weld Deposit0.060.251.40
SW 702 MoWeld Deposit0.080.251.300.40
SW 702SiWeld Deposit0.070.351.45
SW 703SiWeld Deposit0.060.351.65

Typical Mechanical Values of Weld Metal(%)

Test ConditionWelding WireYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As weldedSW 70241051030-20°C → 120-40°C → 100-50°C → 65
As weldedSW 702 Mo51059028-20°C → 130-30°C → 80-40°C → 70
As weldedSW 702Si42052030-20°C → 140-40°C → 110-50°C → 70
As weldedSW 703Si47056030-40°C → 120-50°C → 75-60°C → 50

Wire-Flux Combinations Standards

Welding WireEN Designation of WireEN ISO/TS EN ISO 14171 - AAWS Designation of WireAWS/ASME SFA 5.17/SFA 5.23
SW 702S2S 38 5 AB S2EM12F7 A6 EM-12
SW 702 MoS2MoS 46 4 AB S2MoEA2F8 A5 EA2
SW 702SiS2SiS 38 5 AB S2SiEM12KF7 A6 EM-12K
SW 703SiS3SiS 46 5 AB S3SiEH12KF7 A8 EH-12K

Application Information

Welding Positions :
Sf 414 Kaynak Pozisyonu Sf 414 Kaynak Pozisyonu Sf 414 Kaynak Pozisyonu

Polarity:

Sf 414 Kutuplama DC(+)

Welding Parameters & Efficiency :

Packaging Information

Product CodeWeight Of The Box (kg)Number Of Boxes Per PackageWeight Of The PackagePackaging Type
401050AGM225.0125.6Kraft Bag
401050JGM225.0125.6DRY PACK PE TORBA
401050JJM225.0125.6DRY PACK PE TORBA

Storage & Re-Drying Information

>The total drying duration should not exceed 10 hours ( also for repeated drying).
>During transportation and storage, it should be ensured that the packaging is not damaged or torn.
>It has to be dried at 350°C for 2 hours.
