SI 307

Standards

AWS/ASME SFA - 5.9 ~ER307
EN ISO 14343 - A S 18 8 Mn
TS EN ISO 14343 - A S 18 8 Mn
DIN M. No. 1.4370

Properties and Applications

Austenitic stainless steel welding wire for submerged arc welding of dissimilar steels, difficult to weld steels, armour plates, high manganese steels, rails, crossovers. Suitable also for depositing stress relieving buffer layers on crack sensitive base metals and hardsurfacing, e.g. crane wheels, cutting blades and dies where high degree of pressure and dynamical loads exists. Weld metal is resistant to operating temperatures up to 300°C and non-scalling up to 850°C and also highly corrosion resistant. Used in combination with SIF 501 and SIF 502 submerged arc welding fluxes. Depending on chemical composition of base metal, proper welding procedure, preheating and interpass temperatures shall be applied by also avoiding high admixture of base metal.
Si 307 Sert Dolgu

Typical Chemical Features of the Welding Wire

Type of AnalysisCSiMnCrNi
Welding Wire0.020.905.0019.008.00

Typical Chemical Values of Weld Metal

Welding FluxType of AnalysisCSiMnCrNi
SIF 502Weld Deposit0.040.905.0018.508.00
SIF 501Weld Deposit0.040.855.5018.507.00

Typical Mechanical Values of Weld Metal(%)

Test ConditionWelding FluxYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As weldedSIF 5024206104020°C → 60-60°C → 45
As weldedSIF 5014106004220°C → 70-60°C → 50

Application Information

Welding Positions :
Si 307 Kaynak Pozisyonu Si 307 Kaynak Pozisyonu

Polarity:

Si 307 Kutuplama

Welding Parameters & Efficiency :

Diameter (mm)
2.40
3.20

Packaging Information

Product CodeDiameter (mm)Quantity per BoxBox Gross Weight (kg)Boxes per Outer BoxOuter Box Gross Weight (kg)Packaging Type
43000IXAM22.4025 kg25.90125.90Wire Basket Spool (K435)
43000LXAM23.2025 kg25.90125.90Wire Basket Spool (K435)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
