Sw 702

Properties and Applications

Solid, submerged arc welding wire suitable for welding general structural steels with medium and high tensile strengths, used in pressure vessel, boiler, pipe, shipbuilding and steel constructions. Also suitable to use in combination with SHF 325, SHF 335 and SHF 345 hardfacing fluxes for hardfacing applications. Copper coating increases electrical conductivity and resistance against rusting.

Typical Chemical Features of the Welding Wire

Type of Analysis	C	Si	Mn
Welding Wire	0.09	0.08	1.10

Type of Analysis

Welding Wire

0.09

0.08

1.10

Typical Chemical Values of Weld Metal

Welding Flux	Type of Analysis	C	Si	Mn
SF 204	Weld Deposit	0.05	0.40	1.40
SF 212	Weld Deposit	0.05	0.70	1.35
SF 414	Weld Deposit	0.06	0.25	1.40
SF 113	Weld Deposit	0.04	0.40	1.80
SF 134	Weld Deposit	0.05	0.45	1.45
SF 104	Weld Deposit	0.05	0.30	1.10
SF 304	Weld Deposit	0.05	0.25	1.25
SF 124	Weld Deposit	0.05	0.20	1.10

Typical Mechanical Values of Weld Metal(%)

Test Condition	Welding Flux	Yield Strength (N/mm²)	Tensile Strength (N/mm²)	Elongation A5 (%)	Charpy V-Notch Properties (J)
As welded	SF 104	420	500	28	-20°C → 65	-30°C → 45
As welded	SF 304	430	500	29	20°C → 110	-30°C → 75	-40°C → 60
As welded	SF 124	430	490	30	-20°C → 70	-40°C → 40
As welded	SF 204	435	510	30	-20°C → 90	-30°C → 70	-40°C → 50
As welded	SF 212	480	560	28	20°C → 70	0°C → 30
As welded	SF 414	410	510	30	-20°C → 120	-40°C → 100	-50°C → 65
As welded	SF 113	400	500	30	0°C → 65	-20°C → 55
As welded	SF 134	440	530	30	-30°C → 90	-40°C → 50

Application Information

Welding Positions :

Polarity:

Welding Parameters & Efficiency :

Diameter (mm)
1.60
2.00
2.40
3.00
3.20
4.00
5.00

Packaging Information

Product Code	Diameter (mm)	Quantity per Box	Kutu Brüt Ağırlığı (kg)	Boxes per Outer Box	Koli Ağırlığı (kg)	Packaging Type
41002G1HM2	1.60	250 kg	257.50	1	257.50	Fiber Drum
41002GJAM5	1.60	15 kg	15.70	1	15.70	Wire Basket Spool (K300MS)
41002H2HM2	2.00	400 kg	415.60	1	415.60	Fiber Drum
41002HXAM2	2.00	25 kg	25.90	1	25.90	Wire Basket Spool (K435)
41002I2HM2	2.40	400 kg	415.60	1	415.60	Fiber Drum
41002I3HM2	2.40	600 kg	616.50	1	616.50	Fiber Drum
41002I8HM2	2.40	1000 kg	1030.00	1	1030.00	Spider
41002IXAM2	2.40	25 kg	25.90	1	25.90	Wire Basket Spool (K435)
41002KXAM2	3.00	25 kg	25.90	1	25.90	Wire Basket Spool (K435)
41002L2HM2	3.20	400 kg	415.60	1	415.60	Fiber Drum
41002L3HM2	3.20	550 kg	616.50	1	616.50	Fiber Drum
41002L8HM2	3.20	1000 kg	1030.00	1	1030.00	Spider
41002L9GM2	3.20	1000 kg	0.00	1	0.00	COIL
41002LXAM2	3.20	25 kg	25.90	1	25.90	Wire Basket Spool (K435)
41002M2HM2	4.00	400 kg	415.60	1	415.60	Fiber Drum
41002M3HM2	4.00	600 kg	616.50	1	616.50	Fiber Drum
41002M8HM2	4.00	1000 kg	1030.00	1	1030.00	Spider
41002M9GM2	4.00	1000 kg	0.00	1	0.00	COIL
41002MXAM2	4.00	25 kg	25.90	1	25.90	Wire Basket Spool (K435)
41002NXAM2	5.00	25 kg	25.90	1	25.90	Wire Basket Spool (K435)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.

AWS/ASME SFA - 5.17	EM12
EN ISO 14171-A	S2
TS EN ISO 14171-A	S2

Standards

Approvals & Certificates
