SW 702Si

Datasheet

Standards

AWS/ASME SFA - 5.17	EM12K
EN ISO 14171-A	S2Si
TS EN ISO 14171-A	S2Si

Properties And Applications

Solid, submerged arc welding wire suitable for welding general structural steels with medium and high tensile strengths, used in pressure vessel, boiler, pipe, shipbuilding and steel constructions. Higher silicon content improves deoxidation of weld pool. Copper coating increases electrical conductivity and resistance against rusting.

Approvals & Certificates

TUV

TSE

Typical Chemical Features of the Welding Wire

Type of Analysis	C	Si	Mn
Welding Wire	0.09	0.25	1.10

Type of Analysis

Welding Wire

0.09

0.25

1.10

Typical Chemical Values of Weld Metal

Welding Flux	Type of Analysis	C	Si	Mn
SF 204	Weld Deposit	0.06	0.55	1.35
SF 212	Weld Deposit	0.05	0.80	1.40
SF 414	Weld Deposit	0.07	0.35	1.45
SF 113	Weld Deposit	0.04	0.65	1.90
SF 134	Weld Deposit	0.05	0.60	1.60
SF 401	Weld Deposit	0.06	0.30	1.15
SF 104	Weld Deposit	0.04	0,50	1.10
SF 304	Weld Deposit	0.06	0.45	1.40
SF 124	Weld Deposit	0.05	0.30	1.20

Typical Mechanical Values of Weld Metal(%)

Test Condition	Welding Flux	Yield Strength (N/mm²)	Tensile Strength (N/mm²)	Elongation A5 (%)	Charpy V-Notch Properties (J)
As welded	SF 104	425	510	29	0°C → 80	-20°C → 50	-30°C → 40
As welded	SF 304	460	530	28	-20°C → 90	-30°C → 70	-40°C → 50
As welded	SF 124	435	500	27	-20°C → 90	-30°C → 70	-40°C → 50
As welded	SF 204	440	530	29	-30°C → 70	-40°C → 40
As welded	SF 212	490	570	28	20°C → 80	0°C → 55
As welded	SF 414	420	520	30	-20°C → 140	-40°C → 110	-50°C → 70
As welded	SF 113	450	550	30	0°C → 60	-20°C → 50
As welded	SF 134	470	560	29	-20°C → 90	-30°C → 70	-40°C → 45
As welded	SF 401	425	520	30	-30°C → 110	-40°C → 90	-50°C → 70

Test Condition

Welding Flux

Yield Strength (N/mm²)

Tensile Strength (N/mm²)

Elongation A5 (%)

Charpy V-Notch Properties (J)

As welded

SF 104

425

510

0°C → 80

-20°C → 50

-30°C → 40

As welded

SF 304

460

530

-20°C → 90

-30°C → 70

-40°C → 50

As welded

SF 124

435

500

-20°C → 90

-30°C → 70

-40°C → 50

As welded

SF 204

440

530

-30°C → 70

-40°C → 40

As welded

SF 212

490

570

20°C → 80

0°C → 55

As welded

SF 414

420

520

-20°C → 140

-40°C → 110

-50°C → 70

As welded

SF 113

450

550

0°C → 60

-20°C → 50

As welded

SF 134

470

560

-20°C → 90

-30°C → 70

-40°C → 45

As welded

SF 401

425

520

-30°C → 110

-40°C → 90

-50°C → 70

Application Information

Welding Positions :

Polarity:

Welding Parameters & Efficiency :

Diameter (mm)
1.60
2.00
2.40
3.20
4.00

Diameter (mm)

1.60

2.00

2.40

3.20

4.00

Packaging Information

Product Code	Diameter (mm)	Quantity per Box	Kutu Brüt Ağırlığı (kg)	Boxes per Outer Box	Koli Ağırlığı (kg)	Packaging Type
41003G1GM2	1.60	250 kg	257.50	1	257.50	Fiber Drum
41003G1JM2	1.60	250 kg	261.00	1	261.00	Fiber Drum
41003GMAM2	1.60	15 kg	15.70	1	15.70	Wire Basket Spool (K300)
41003GXAM2	1.60	25 kg	25.90	1	25.90	Wire Basket Spool (K435)
41003H2HM2	2.00	400 kg	415.60	1	415.60	Fiber Drum
41003HXAM2	2.00	25 kg	25.90	1	25.90	Wire Basket Spool (K435)
41003I2HM2	2.40	400 kg	415.60	1	415.60	Fiber Drum
41003IXAM2	2.40	25 kg	25.90	1	25.90	Wire Basket Spool (K435)
41003IYAM2	2.40	100 kg	102.00	1	102.00	Tel Makara (K785)
41003L2HM2	3.20	400 kg	415.60	1	415.60	Fiber Drum
41003L3HM2	3.20	600 kg	616.50	1	616.50	Fiber Drum
41003L9GM2	3.20	1000 kg	0.00	1	0.00	COIL
41003LXAM2	3.20	25 kg	25.90	1	25.90	Wire Basket Spool (K435)
41003LXBM2	3.20	25 kg	25.90	1	25.90	Wire Basket Spool (K435)
41003M2HM2	4.00	400 kg	415.60	1	415.60	Fiber Drum
41003M3HM2	4.00	550 kg	616.50	1	616.50	Fiber Drum
41003M9GM2	4.00	1000 kg	0.00	1	0.00	COIL
41003MXAM2	4.00	25 kg	25.90	1	25.90	Wire Basket Spool (K435)
41003MYAM2	4.00	100 kg	102.00	1	102.00	Tel Makara (K785)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
