TAL 1100

Datasheet

Standards

AWS/ASME SFA - 5.10 ~ER1100
AWS/ASME SFA - 5.10 ER1070
EN ISO 18273 S Al 1070 (Al99.7)
TS 6204 EN ISO 18273 S Al 1070 (Al99.7)
DIN M. No. 3.0259

Materials

DIN Material
Al 99.0 3.0205
Al 99.5 3.0255
Al 99.7 3.0275
Al 99.8 3.0285

Properties and Applications

Pure aluminium GTA(TIG) welding of unalloyed aluminium base metals. It has got good colour matching with the aluminium base metals. High corrosion resistance and excellent electrical conductivity.
Tal 1100 Sert Dolgu

Typical Chemical Features of the Welding Wire

Type of AnalysisAl
Welding Wire99.7

Typical Mechanical Values of Weld Metal(%)

Test ConditionProtection GasYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)
As weldedI1507035

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - I1 (%100 Ar) .

Application Information

Welding Positions :
Tal 1100 Kaynak Pozisyonu Tal 1100 Kaynak Pozisyonu Tal 1100 Kaynak Pozisyonu Tal 1100 Kaynak Pozisyonu Tal 1100 Kaynak Pozisyonu Tal 1100 Kaynak Pozisyonu

Polarity:

Tal 1100 Kutuplama

Protection Gas:

I1

Welding Parameters & Efficiency :

Packaging Information

Product CodeDiameter X Length (mm)Kutudaki Miktar (yakl)Kutu Net Ağırlığı (kg)Number Of Boxes In PackageKoli Net Ağırlığı (kg)Packaging Type
24100GAKM21.60x10003 kg2.5411.3Cardboard Tube
24100HAKM22.00x10003 kg2.5411.3Cardboard Tube
24100IAKM22.40x10003 kg2.5411.3Cardboard Tube

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
